0026497054

Active

Molex

CONN HEADER VERT 5POS 3.96MM

Search across all available documentation for this part.

Active

Molex

CONN HEADER VERT 5POS 3.96MM

Technical Specifications

Parameters and characteristics for this part

Specification	0026497054

Applications	Industrial, Automotive, Medical, General Purpose, Telecommunications
Connector Type	Breakaway, Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	30 Áin
Contact Finish Thickness - Mating	0.76 Ám
Contact Finish Thickness - Post	2.54 µm
Contact Finish Thickness - Post	100 µin
Contact Length - Mating	11.43 mm
Contact Length - Mating	0.45 in
Contact Length - Post	0.172 in
Contact Length - Post	4.37 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Friction Lock
Insulation Color	Black
Insulation Height	0.5 in
Insulation Height	12.7 mm
Insulation Material	Polyester
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions Loaded	4
Number of Rows	1
Overall Contact Length	0.75 in
Overall Contact Length	19.05 mm
Pitch - Mating	0.156 in
Pitch - Mating	3.96 mm
Shrouding	Shrouded - 1 Wall
Style	Board to Board, Cable
Termination	Solder

Part	Contact Length - Post	Contact Length - Post	Applications	Contact Type	Pitch - Mating	Pitch - Mating	Contact Shape	Fastening Type	Contact Finish - Mating	Connector Type	Number of Positions Loaded	Contact Finish - Post	Shrouding	Termination	Material Flammability Rating	Mounting Type	Contact Material	Style	Number of Rows	Insulation Height	Insulation Height	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Mating	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Material	Insulation Color	Number of Positions
Molex 0026497054	0.172 in	4.37 mm	Automotive General Purpose Industrial Medical Telecommunications	Male Pin	0.156 in	3.96 mm	Square	Friction Lock	Gold	Breakaway Header	4	Tin	Shrouded - 1 Wall	Solder	UL94 V-0	Through Hole	Brass	Board to Board Cable	1	0.5 in	12.7 mm	2.54 µm	100 µin	11.43 mm	0.45 in	0.75 in	19.05 mm	30 Áin	0.76 Ám	Polyester	Black
Molex 0026497084			Automotive General Purpose Industrial Medical Telecommunications	Male Pin	0.156 in	3.96 mm	Square	Friction Lock	Gold	Breakaway Header	7	Tin	Shrouded - 1 Wall	Solder	UL94 V-0	Through Hole	Brass	Board to Board Cable	1	0.5 in	12.7 mm	2.54 µm	100 µin					30 Áin	0.76 Ám	Polyester	Black	8
Molex 0026496100			Automotive General Purpose Industrial Medical Telecommunications	Male Pin	0.156 in	3.96 mm	Square	Friction Lock		Breakaway Header	9	Tin	Shrouded - 1 Wall	Solder	UL94 V-0	Through Hole	Brass	Board to Board Cable	1	0.5 in	12.7 mm	1.52 µm	60 µin					60 Áin	1.52 Ám	Polyester	Black	10

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	2400	$ 1.64

General part information

Connector Header Through Hole 5 position 0.156" (3.96mm)

Technical documentation and resources
