040MS22AAMK1STD
ActiveKEMET
CAP ALUM 40UF 10% 220V QC CHAS M
Deep-Dive with AI
Search across all available documentation for this part.
040MS22AAMK1STD
ActiveKEMET
CAP ALUM 40UF 10% 220V QC CHAS M
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 040MS22AAMK1STD |
|---|---|
| Applications | Motor Start |
| Capacitance | 40 µF |
| Height - Seated (Max) [Max] [z] | 2.953 in |
| Height - Seated (Max) [Max] [z] | 75 mm |
| Lifetime @ Temp. | 500 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 C |
| Package / Case | Radial, Can - QC Terminals |
| Size / Dimension [diameter] | 1.535 in |
| Size / Dimension [diameter] | 39 mm |
| Tolerance | 10 % |
| Voltage - Rated | 220 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 6.30 | |
| 10 | $ 5.46 | |||
| 72 | $ 4.90 | |||
| 144 | $ 4.25 | |||
| 504 | $ 3.85 | |||
| 1008 | $ 3.57 | |||
| 2520 | $ 3.50 | |||
Description
General part information
040MS Series
40 µF 220 V Aluminum Electrolytic Capacitors Radial, Can - QC Terminals 500 Hrs @ 60°C
