LDW120-48P

Active

EOS Power India Private Ltd

AC/DC DIN RAIL SUPPLY 48V 120W

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

AC/DC DIN RAIL SUPPLY 48V 120W

Technical Specifications

Parameters and characteristics for this part

Specification	LDW120-48P

AC Voltage - Input [Max]	2 Phase, 550 VAC
AC Voltage - Input [Min]	187 VAC, 1 Phase
Applications	ITE (Commercial)
Current - Output (Max) [Max]	2.5 A
DC Voltage - Input (Max) [Max]	725 V
DC Voltage - Input (Min) [Min]	250 V
Efficiency	86 %
Features	Load Sharing, IP20, Adjustable Output
Input Type	AC or DC
Number of Outputs	1
Size / Dimension [x]	4.33 in
Size / Dimension [x]	110 mm
Size / Dimension [y]	40 mm
Size / Dimension [y]	1.57 "
Size / Dimension [z]	115 mm
Size / Dimension [z]	4.53 "
Voltage - Isolation	4.2 kV
Voltage - Output 1	48 V

Part	DC Voltage - Input (Min) [Min]	Efficiency	DC Voltage - Input (Max) [Max]	Voltage - Output 1	Features	Applications	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Voltage - Isolation	Number of Outputs	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Input Type	Current - Output (Max) [Max]
EOS Power India Private Ltd LDW120-48P	250 V	86 %	725 V	48 V	Adjustable Output IP20 Load Sharing	ITE (Commercial)	1 Phase 187 VAC	2 Phase 550 VAC	4.2 kV	1	115 mm	4.33 in	4.53 "	40 mm	1.57 "	110 mm	AC or DC	2.5 A
EOS Power India Private Ltd LDW120-24	250 V	88 %	725 V	24 V	Adjustable Output IP20	ITE (Commercial)	1 Phase 187 VAC	2 Phase 550 VAC	4.2 kV	1	115 mm	4.33 in	4.53 "	40 mm	1.57 "	110 mm	AC or DC	5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	15	$ 209.27

General part information

AC/DC DIN RAIL SUPPLY 48V 120W

Technical documentation and resources

No documents available
