MOVHE10V175Y
ActiveEaton - Electronics Division
VARISTOR 175 VAC HE 10MM DISC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MOVHE10V175Y
ActiveEaton - Electronics Division
VARISTOR 175 VAC HE 10MM DISC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MOVHE10V175Y |
|---|---|
| Capacitance @ Frequency | 370 pF |
| Current - Surge | 3.5 kA |
| Energy | 49 J |
| Maximum AC Volts [Max] | 175 V |
| Maximum DC Volts [Max] | 225 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Disc |
| Package / Case [diameter] | 10 mm |
| Varistor Voltage (Max) [Max] | 297 V |
| Varistor Voltage (Min) [Min] | 243 V |
| Varistor Voltage (Typ) | 270 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 0.56 | |
| 10 | $ 0.34 | |||
| 25 | $ 0.29 | |||
| 100 | $ 0.22 | |||
| 250 | $ 0.19 | |||
| 500 | $ 0.17 | |||
| 1000 | $ 0.15 | |||
| 2500 | $ 0.13 | |||
| 5000 | $ 0.12 | |||
Description
General part information
MOVHE10 Series
270 V 3.5 kA Varistor 1 Circuit Through Hole Disc 10mm
