0395943012
ActiveMolex
TERM BLK 12P SIDE ENT 5.08MM PCB
Deep-Dive with AI
Search across all available documentation for this part.
0395943012
ActiveMolex
TERM BLK 12P SIDE ENT 5.08MM PCB
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 0395943012 |
|---|---|
| Clamp Material - Plating | Brass |
| Color | Green |
| Contact Material - Plating [custom] | Brass - Tin Plated |
| Current | 15 A |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 0.2 in |
| Pitch [x] | 5.08 mm |
| Positions Per Level | 12 |
| Screw Material - Plating | Steel |
| Torque - Screw | 0.51 Nm |
| Torque - Screw | 4.5 Lb-In |
| Voltage | 300 V |
| Wire Gauge [Max] | 30 AWG |
| Wire Gauge [Min] | 12 AWG |
| Wire Termination | Screw - Rising Cage Clamp |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 5.27 | |
| 10 | $ 4.01 | |||
| 25 | $ 3.76 | |||
| 50 | $ 3.34 | |||
| 100 | $ 3.27 | |||
| 480 | $ 2.72 | |||
| 960 | $ 2.42 | |||
Description
General part information
039594 Series
12 Position Wire to Board Terminal Block Horizontal with Board 0.200" (5.08mm) Through Hole
