AMED60-5SNZ
Obsoleteaimtec
AC-DC REGULATED POWER SUPPLY MODULE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMED60-5SNZ |
|---|---|
| AC Voltage - Input [Max] | 264 VAC |
| AC Voltage - Input [Min] | 85 VAC |
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 6.5 A |
| DC Voltage - Input (Max) [Max] | 370 V |
| DC Voltage - Input (Min) [Min] | 120 V |
| Efficiency | 84 % |
| Features | Universal Input |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 33 W |
| Size / Dimension [x] | 58 mm |
| Size / Dimension [x] | 2.28 in |
| Size / Dimension [y] | 2.05 in |
| Size / Dimension [y] | 52 mm |
| Size / Dimension [z] | 3.65 in |
| Size / Dimension [z] | 92.7 mm |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 32.63 | |
Description
General part information
AMED60 Series
AC-DC REGULATED POWER SUPPLY MODULE
