Q-080690008024i

Active

Amphenol Custom Cable

CBL ASSY RPSMA-BNC PLUG-JACK 24"

Deep-Dive with AI

Search across all available documentation for this part.

Q-080690008024i

Active

Amphenol Custom Cable

CBL ASSY RPSMA-BNC PLUG-JACK 24"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-080690008024i

1st Connector	RP-SMA Plug
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Female
2nd Connector	BNC Jack
2nd Connector Mounting Feature	Bulkhead - Front Side Nut
2nd Connector Mounting Type	Panel Mount
2nd Contact Gender	Female
Cable Type	RG-58
Color	Black
Features	Shielded
Frequency - Max [Max]	4 GHz
Length	24 "
Length	609.6 mm
Overall Impedance	50 Ohms
Style	RP-SMA to BNC

Q-080690 Series

Part	2nd Connector Mounting Feature	Cable Type	Length	Length	Length	Overall Impedance	1st Contact Gender	1st Connector	2nd Connector Mounting Type	Color	2nd Contact Gender	2nd Connector	1st Connector Mounting Type	Style	Features	Frequency - Max [Max]	Length [x]	Length [x]	Length [x]
Amphenol Custom Cable Q-080690008060i	Bulkhead - Front Side Nut	RG-58	5 ft	1.5 m	5 '	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-080690008072i	Bulkhead - Front Side Nut	RG-58	6 ft	1.8 m	72 in	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-0806900081.5M	Bulkhead - Front Side Nut	RG-58	4.9 ft	1.5 m	59.1 in	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-080690008108i	Bulkhead - Front Side Nut	RG-58	9 ft	2.7 m	108 in	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-080690008024i	Bulkhead - Front Side Nut	RG-58		609.6 mm	24 "	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-080690008003M	Bulkhead - Front Side Nut	RG-58	9.8 '	3 m	118.1 in	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-080690008018i	Bulkhead - Front Side Nut	RG-58				50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz	457.2 mm	457.2 mm
Amphenol Custom Cable Q-080690008084i	Bulkhead - Front Side Nut	RG-58	7 ft	2.1 m	84 in	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz
Amphenol Custom Cable Q-080690008.25M	Bulkhead - Front Side Nut	RG-58				50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz		250 mm	9.843 "
Amphenol Custom Cable Q-080690008002M	Bulkhead - Front Side Nut	RG-58	6.6 ft	2 m	78.7 in	50 Ohms	Female	RP-SMA Plug	Panel Mount	Black	Female	BNC Jack	Free Hanging (In-Line)	RP-SMA to BNC	Shielded	4 GHz

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 79.84
		25	$ 78.94
		50	$ 78.04
		100	$ 77.14
		250	$ 76.25

Description

General part information

Q-080690 Series

Cable Assembly Coaxial RP-SMA to BNC RG-58 24.00" (609.60mm)

Documents

Technical documentation and resources

No documents available
