GTM91128LI3C1000T00

Active

GlobTek, Inc.

BATT CHARGER WALL MT 12.6V 1A

Search across all available documentation for this part.

Active

GlobTek, Inc.

BATT CHARGER WALL MT 12.6V 1A

Technical Specifications

Parameters and characteristics for this part

Specification	GTM91128LI3C1000T00

Approval Agency	CE, EAC, SIQ, cURus, WEEE, CB, S-Mark, GS, ETL, PSE, VCCC
Battery Chemistry	Lithium-Ion
Charge Current - Max [Max]	1 A
Features	Interchangeable Blades
Mounting Type	Wall Mount
Number of Cells	3
Operating Temperature [custom]	35 °C, 0 °C
Power - Max [Max]	12.6 W
Size / Dimension [x]	4.63 in
Size / Dimension [x]	117.5 mm
Size / Dimension [y]	53.5 mm
Size / Dimension [y]	2.11 in
Size / Dimension [z]	36.6 mm
Size / Dimension [z]	1.44 "
Termination Style	Barrel Plug Kit (1.3mm x 3.5mm, 2.1mm x 5.5mm, 2.5mm x 5.5mm)
Type	Wall Mount, Desktop
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Nominal	12.6 V

Part	Voltage - Input [Max]	Voltage - Input [Min]	Type	Features	Number of Cells	Termination Style	Battery Chemistry	Approval Agency	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [custom]	Mounting Type	Voltage - Nominal	Charge Current - Max [Max]	Power - Max [Max]
GlobTek, Inc. GTM91128LI3C1000T00	264 VAC	90 VAC	Desktop Wall Mount	Interchangeable Blades	3	Barrel Plug Kit (1.3mm x 3.5mm 2.1mm x 5.5mm 2.5mm x 5.5mm)	Lithium-Ion	CB CE cURus EAC ETL GS PSE S-Mark SIQ VCCC WEEE	36.6 mm	4.63 in	53.5 mm	1.44 "	117.5 mm	2.11 in	0 °C 35 °C	Wall Mount	12.6 V	1 A	12.6 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Desktop, Wall Mount Battery Charger 12.6V 1A
