HT46C/4P-M12

Active

Leuze

DIFFUSE BACKGROUND SUPPRESSION

Search across all available documentation for this part.

Active

Leuze

DIFFUSE BACKGROUND SUPPRESSION

Technical Specifications

Parameters and characteristics for this part

Specification	HT46C/4P-M12

Adjustment Type	Adjustable
Connection Method	Connector, M12
Ingress Protection	IEC 60947-5-2 IP67, IEC 60947-5-2 IP69K, IP67, IEC 60947-5-2, IP69K
Light Source	Red LED
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-40 °C
Output Configuration	PNP - Dark-ON/Light-ON
Response Time	2 ms
Sensing Method	Diffuse, Background Suppression
Voltage - Supply [Max]	30 VDC
Voltage - Supply [Min]	10 VDC

Part	Sensing Method	Voltage - Supply [Max]	Voltage - Supply [Min]	Ingress Protection	Response Time	Output Configuration	Connection Method	Light Source	Adjustment Type	Operating Temperature [Min]	Operating Temperature [Max]	Light Source
Leuze HT46C/4P-M12	Background Suppression Diffuse	30 VDC	10 VDC	IEC 60947-5-2 IEC 60947-5-2 IP67 IEC 60947-5-2 IP69K IP67 IP69K	2 ms	PNP - Dark-ON/Light-ON	Connector M12	Red LED	Adjustable	-40 °C	60 °C
Leuze HT46CI/4P-M12	Background Suppression Diffuse	30 VDC	10 VDC	IEC 60947-5-2 IP67 IEC 60947-5-2 IP69K	2 ms	PNP - Dark-ON/Light-ON	Connector M12	Infrared		-40 °C	60 °C	860 nm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 216.74

General part information

Diffuse, Background Suppression Optical Sensor 0.197" ~ 118.110" (5mm ~ 3m) PNP - Dark-ON/Light-ON
