TC78B009FTG,EL
ActiveToshiba Semiconductor and Storage
30V, 3-PHASE BRUSHLESS DC (BLDC)
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TC78B009FTG,EL
ActiveToshiba Semiconductor and Storage
30V, 3-PHASE BRUSHLESS DC (BLDC)
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TC78B009FTG,EL |
|---|---|
| Applications | General Purpose |
| Current - Output | 240 mA |
| Function | Controller - Commutation, Direction Management |
| Interface | I2C, PWM |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Motor Type - Stepper | Multiphase |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Pre-Driver - High Side/Low Side |
| Package / Case | 36-WFQFN Exposed Pad |
| Supplier Device Package | 36-WQFN (5x5) |
| Technology | NMOS |
| Voltage - Supply [Max] | 27 V |
| Voltage - Supply [Min] | 5.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.88 | |
| 10 | $ 2.50 | |||
| 25 | $ 2.13 | |||
| 100 | $ 1.72 | |||
| 250 | $ 1.52 | |||
| 500 | $ 1.39 | |||
| 1000 | $ 1.29 | |||
| 2500 | $ 1.23 | |||
| Digi-Reel® | 1 | $ 3.88 | ||
| 10 | $ 2.50 | |||
| 25 | $ 2.13 | |||
| 100 | $ 1.72 | |||
| 250 | $ 1.52 | |||
| 500 | $ 1.39 | |||
| 1000 | $ 1.29 | |||
| 2500 | $ 1.23 | |||
| Tape & Reel (TR) | 5000 | $ 1.23 | ||
Description
General part information
TC78B009 Series
Multiphase Motor Driver NMOS I2C, PWM 36-WQFN (5x5)
Documents
Technical documentation and resources
