1225-25-B-12

Active

RAF Electronic Hardware

1/2 RD X 3/4 X .252 ID

Search across all available documentation for this part.

Active

RAF Electronic Hardware

1/2 RD X 3/4 X .252 ID

Technical Specifications

Parameters and characteristics for this part

Part	Length - Overall [x]	Length - Overall [x]	Length - Overall [x]	Diameter - Inside [diameter]	Diameter - Inside [diameter]	Gender	Type	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Color	Material	Plating	Between Board Height	Between Board Height	Between Board Height	Threaded/Unthreaded
RAF Electronic Hardware 1225-25-B-12	0.75 in	19.05 mm	0.75 in	6.4 mm	0.252 in	Female	Round Spacer	0.5 in	12.7 mm	0.5 in	Clear	Brass	Chromate Zinc	0.75 in	0.75 in	19.05 mm	Unthreaded
RAF Electronic Hardware 1225-25-N	0.75 in	19.05 mm	0.75 in	6.4 mm	0.252 in	Female	Round Spacer	0.5 in	12.7 mm	0.5 in		Nylon		0.75 in	0.75 in	19.05 mm	Unthreaded
RAF Electronic Hardware 1225-25-SS	0.75 in	19.05 mm	0.75 in	6.4 mm	0.252 in	Female	Round Spacer	0.5 in	12.7 mm	0.5 in		Stainless Steel		0.75 in	0.75 in	19.05 mm	Unthreaded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Round Spacer Unthreaded Brass 0.750" (19.05mm) 3/4" Clear
