15683C

Active

Murata Power Solutions Inc.

FIXED IND 68UH 3.33A 70.3MOHM TH

Deep-Dive with AI

DocumentsPower Magnetics Selection Guide Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	15683C

Current Rating (Amps)	3.33 A
DC Resistance (DCR) [Max]	70.3 mOhm
Frequency - Self Resonant	4 MHz
Height - Seated (Max) [Max] [z]	21.3 mm
Height - Seated (Max) [Max] [z]	0.839 in
Inductance	68 µH
Inductance Frequency - Test	10 kHz
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Vertical Cylinder
Q @ Freq	100, 1 MHz
Shielding	Unshielded
Size / Dimension [diameter]	0.661 in
Size / Dimension [diameter]	16.8 mm
Tolerance	10 %
Type	Wirewound

15 Series

Part	Current Rating (Amps)	Frequency - Self Resonant	DC Resistance (DCR)	Inductance Frequency - Test	Shielding	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Inductance	Type	Q @ Freq	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	DC Resistance (DCR) [Max]
Murata Power Solutions Inc. 15153C	7.44 A	19 MHz	15.5 mOhm	10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	15 µH	Wirewound	109	Radial Vertical Cylinder	21.3 mm	0.839 in
Murata Power Solutions Inc. 15683C	3.33 A	4 MHz		10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	68 µH	Wirewound	1 MHz 100	Radial Vertical Cylinder	21.3 mm	0.839 in	70.3 mOhm
Murata Power Solutions Inc. 15103C	9.01 A	30 MHz		10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	10 µH	Wirewound	1 MHz 112	Radial Vertical Cylinder	21.3 mm	0.839 in	10.6 mOhm
Murata Power Solutions Inc. 15333C	5.08 A	8 MHz		10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	33 µH	Wirewound	1 MHz 107	Radial Vertical Cylinder	21.3 mm	0.839 in	31.2 mOhm
Murata Power Solutions Inc. 15334C	1.71 A	1.6 MHz		10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	330 µH	Wirewound	20 kHz 68	Radial Vertical Cylinder	21.3 mm	0.839 in	263 mOhm
Murata Power Solutions Inc. 15152C	14.9 A	108 MHz		10 kHz	Unshielded	20 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	1.5 µH	Wirewound	1 MHz 155	Radial Vertical Cylinder	21.3 mm	0.839 in	3.48 mOhm
Murata Power Solutions Inc. 15222C	15 A	82 MHz		10 kHz	Unshielded	20 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	2.2 µH	Wirewound	1 MHz 127	Radial Vertical Cylinder	21.3 mm	0.839 in	4.2 mOhm
Murata Power Solutions Inc. 15224C	2.08 A	2 MHz		10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	220 µH	Wirewound	20 kHz 69	Radial Vertical Cylinder	21.3 mm	0.839 in	185 mOhm
Murata Power Solutions Inc. 15102C	16.2 A	142 MHz	2.76 mOhm	10 kHz	Unshielded	20 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	1 µH	Wirewound	1 MHz 151	Radial Vertical Cylinder	21.3 mm	0.839 in
Murata Power Solutions Inc. 15154C	2.28 A	2 MHz		10 kHz	Unshielded	10 %	85 °C	-40 °C	0.661 in	16.8 mm	Through Hole	150 µH	Wirewound	126 800 kHz	Radial Vertical Cylinder	21.3 mm	0.839 in	149 mOhm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 1.74
		5	$ 1.72
		10	$ 1.70
		25	$ 1.68
		50	$ 1.47
		100	$ 1.40
		250	$ 1.37
		500	$ 1.33
		1000	$ 1.29

Description

General part information

15 Series

68 µH Unshielded Wirewound Inductor 3.33 A 70.3mOhm Max Radial, Vertical Cylinder
