Q-0103K00011.5M

Active

Amphenol Custom Cable

CBL ASSY BNC-SMB JACK-JACK 4.9'

Deep-Dive with AI

Search across all available documentation for this part.

Q-0103K00011.5M

Active

Amphenol Custom Cable

CBL ASSY BNC-SMB JACK-JACK 4.9'

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-0103K00011.5M

1st Connector	BNC Jack
1st Connector Mounting Feature	Bulkhead - Front Side Nut
1st Connector Mounting Type	Panel Mount
1st Contact Gender	Female
2nd Connector	SMB Jack
2nd Connector Mounting Feature	Bulkhead - Front Side Nut
2nd Connector Mounting Type	Panel Mount
2nd Contact Gender	Female
Cable Type	RG-178
Color	Copper
Features	Shielded
Frequency - Max [Max]	4 GHz
Length	59.1 in
Length	4.9 ft
Length	1.5 m
Overall Impedance	50 Ohms
Style	BNC to SMB

Q-0103K0 Series

Part	2nd Connector Mounting Feature	Length	Length	Length	Style	Overall Impedance	2nd Connector	2nd Contact Gender	Color	1st Connector	1st Contact Gender	Cable Type	Frequency - Max [Max]	2nd Connector Mounting Type	Features	1st Connector Mounting Type	1st Connector Mounting Feature
Amphenol Custom Cable Q-0103K0001072i	Bulkhead - Front Side Nut	6 ft	72 in	1.8 m	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K00010.5M	Bulkhead - Front Side Nut		19.69 "	50 cm	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001108i	Bulkhead - Front Side Nut	9 ft	108 in	2.7 m	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001003M	Bulkhead - Front Side Nut	9.8 '	118.1 in	3 m	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001009i	Bulkhead - Front Side Nut		9 "	228.6 mm	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K00011.5M	Bulkhead - Front Side Nut	4.9 ft	59.1 in	1.5 m	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001084i	Bulkhead - Front Side Nut	7 ft	84 in	2.1 m	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001036i	Bulkhead - Front Side Nut		36 in	91.44 cm	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001024i	Bulkhead - Front Side Nut		24 "	609.6 mm	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut
Amphenol Custom Cable Q-0103K0001060i	Bulkhead - Front Side Nut	5 ft	5 '	1.5 m	BNC to SMB	50 Ohms	SMB Jack	Female	Copper	BNC Jack	Female	RG-178	4 GHz	Panel Mount	Shielded	Panel Mount	Bulkhead - Front Side Nut

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 84.32
		25	$ 78.54
		50	$ 72.77
		100	$ 67.82
		250	$ 63.70

Description

General part information

Q-0103K0 Series

Cable Assembly Coaxial BNC to SMB RG-178 59.1" (1.5m) 4.9'

Documents

Technical documentation and resources

No documents available
