BK010-05-C-0850-0864-0508-G

Active

GCT

CONN HEADER SMD 5POS 5.08MM

Search across all available documentation for this part.

Active

GCT

CONN HEADER SMD 5POS 5.08MM

Technical Specifications

Parameters and characteristics for this part

Specification	BK010-05-C-0850-0864-0508-G

Connector Type	Header
Contact Finish - Post	Tin
Contact Length - Mating	0.335 in
Contact Length - Mating	8.51 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	7.9 A
Fastening Type	Push-Pull
Features	Pick and Place
Insulation Color	Black
Insulation Height [z]	0.098 in
Insulation Height [z]	2.5 mm
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch - Mating	5.08 mm
Pitch - Mating	0.2 in
Shrouding	Unshrouded
Termination	Solder

Part	Contact Finish - Post	Insulation Height [z]	Insulation Height [z]	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Mounting Type	Pitch - Mating	Pitch - Mating	Number of Positions Loaded	Insulation Material	Contact Shape	Features	Contact Length - Mating	Contact Length - Mating	Fastening Type	Termination	Material Flammability Rating	Shrouding	Contact Material	Number of Rows	Current Rating (Amps)	Contact Type	Number of Positions
GCT BK010-05-C-0850-0864-0508-G	Tin	0.098 in	2.5 mm	Black	-40 °C	105 ░C	Header	Surface Mount	5.08 mm	0.2 in	All	Liquid Crystal Polymer (LCP)	Square	Pick and Place	0.335 in	8.51 mm	Push-Pull	Solder	UL94 V-0	Unshrouded	Brass	1	7.9 A	Male Pin
GCT BK010-10-C-0850-0864-0508-G	Tin	0.098 in	2.5 mm	Black	-40 °C	105 ░C	Header	Surface Mount	5.08 mm	0.2 in	All	Liquid Crystal Polymer (LCP)	Square	Pick and Place	0.335 in	8.51 mm	Push-Pull	Solder	UL94 V-0	Unshrouded	Brass	1	7.9 A	Male Pin	10
GCT BK010-03-C-0850-0864-0508-G	Tin	0.098 in	2.5 mm	Black	-40 °C	105 ░C	Header	Surface Mount	5.08 mm	0.2 in	All	Liquid Crystal Polymer (LCP)	Square	Pick and Place	0.335 in	8.51 mm	Push-Pull	Solder	UL94 V-0	Unshrouded	Brass	1	7.9 A	Male Pin
GCT BK010-02-C-0850-0864-0508-G	Tin	0.098 in	2.5 mm	Black	-40 °C	105 ░C	Header	Surface Mount	5.08 mm	0.2 in	All	Liquid Crystal Polymer (LCP)	Square	Pick and Place	0.335 in	8.51 mm	Push-Pull	Solder	UL94 V-0	Unshrouded	Brass	1	7.9 A	Male Pin	2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Header Surface Mount 5 position 0.200" (5.08mm)
