ABD-04PMFS-SC7001

Active

Amphenol LTW

STANDARD STAMPING PIN

Search across all available documentation for this part.

Active

Amphenol LTW

STANDARD STAMPING PIN

Technical Specifications

Parameters and characteristics for this part

Specification	ABD-04PMFS-SC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	5 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Finish	Nickel
Shell Size - Insert	B
Shielding	Unshielded
Voltage Rating	300 VDC

Part	Insert Material	Material Flammability Rating	Primary Material	Color	Orientation	Shell Finish	Shell Size - Insert	Contact Material	Connector Type	Shielding	Number of Positions	Voltage Rating	Current Rating (Amps)	Mounting Feature	Contact Finish - Mating	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Shell Material
Amphenol LTW ABD-04PMFS-SC7001	Polyamide (PA) Nylon Glass Filled	UL94 V-0	Plastic	Black	Keyed	Nickel	B	Copper Alloy	Receptacle Female Sockets	Unshielded	4	300 VDC	5 A	Bulkhead - Front Side Nut	Gold	IP67 - Dust Tight Waterproof	-40 °C	105 ░C
Amphenol LTW ABD-04PMFS-LC7001	Polyamide (PA) Nylon Glass Filled		Plastic	Black	Keyed		B	Copper Alloy	Receptacle Female Sockets	Unshielded	4	300 VDC	5 A	Bulkhead - Front Side Nut	Gold	IP67 - Dust Tight Waterproof	-40 °C	105 ░C	Bayonet Lock	Glass Filled Nylon Polyamide (PA)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 4.68

General part information

4 Position Circular Connector Receptacle, Female Sockets Solder Cup
