24_QMA-50-3-3/111_NE
ActiveHuber+Suhner, Inc.
RF CONNECTOR, 1 CONTACT(S), FEMALE, PANEL MOUNT, CABLE MOUNT, SOLDER TERMINAL, JACK, ROHS COMPLIANT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
24_QMA-50-3-3/111_NE
ActiveHuber+Suhner, Inc.
RF CONNECTOR, 1 CONTACT(S), FEMALE, PANEL MOUNT, CABLE MOUNT, SOLDER TERMINAL, JACK, ROHS COMPLIANT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 24_QMA-50-3-3/111_NE |
|---|---|
| Body Finish | Gold |
| Body Material | Brass |
| Cable Group | RG-141 |
| Center Contact Material | Beryllium Copper |
| Center Contact Plating | Gold |
| Connector Type | Female Socket, Jack |
| Contact Termination | Crimp |
| Dielectric Material | Perfluoroalkoxy (PFA), Polytetrafluoroethylene (PTFE) |
| Fastening Type | Snap-On |
| Frequency - Max [Max] | 18 GHz |
| Housing Color | Gold |
| Impedance | 50 Ohms |
| Mounting Feature | Bulkhead - Front Side Nut |
| Number of Ports | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Shield Termination | Solder |
| Voltage Rating | 480 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 10 | $ 21.99 | |
Description
General part information
24_QMA-50 Series
QMA Connector Jack, Female Socket 50 Ohms Panel Mount Crimp
