QYW09225024BL-12

Active

YS TECH USA

FAN AXIAL 92X25MM 24VDC WIRE

Search across all available documentation for this part.

Active

YS TECH USA

FAN AXIAL 92X25MM 24VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Specification	QYW09225024BL-12

Air Flow	0.725 m³/min
Air Flow	25.9 CFM
Bearing Type	Ball
Current Rating (Amps)	45 mA
Fan Type	Tubeaxial
Lifetime @ Temp.	80000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	16.7 dB(A)
Power (Watts)	1.08 W
RPM	2000 RPM
Static Pressure	20.6 Pa
Static Pressure	0.083 in H2O
Termination	2 Wire Leads
Voltage - Rated	24 VDC
Voltage Range [Max]	26.4 VDC
Voltage Range [Min]	12 VDC
Width [y]	25 mm

Part	Noise	Voltage Range [Max]	Voltage Range [Min]	Bearing Type	Air Flow	Air Flow	Current Rating (Amps)	Voltage - Rated	Lifetime @ Temp.	Static Pressure	Static Pressure	Fan Type	Termination	Material - Blade	Power (Watts)	RPM	Width [y]
YS TECH USA QYW09225024BL-12	16.7 dB(A)	26.4 VDC	12 VDC	Ball	0.725 m³/min	25.9 CFM	45 mA	24 VDC	80000 Hrs	20.6 Pa	0.083 in H2O	Tubeaxial	2 Wire Leads	Polybutylene Terephthalate (PBT)	1.08 W	2000 RPM	25 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Tubeaxial 24VDC Square - 92mm L x 92mm H Ball 25.9 CFM (0.725m³/min) 2 Wire Leads
