ADJ13012
ActivePanasonic Electric Works
RELAY GEN PURPOSE SPDT 16A 12V
Deep-Dive with AI
Search across all available documentation for this part.
ADJ13012
ActivePanasonic Electric Works
RELAY GEN PURPOSE SPDT 16A 12V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ADJ13012 |
|---|---|
| Approval Agency | CQC, VDE, cURus |
| Coil Current | 20.8 mA |
| Coil Resistance | 576 Ohms |
| Coil Type | Latching, Dual Coil |
| Coil Voltage | 12 VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 16 A |
| Load - Max Switching | 4000 VA |
| Mounting Type | Through Hole |
| Must Operate Voltage | 8.4 VDC |
| Operate Time | 20 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 20 ms |
| Seal Rating | Sealed - Flux Protection |
| Switching Voltage | 250 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 100 | $ 11.30 | |
Description
General part information
ADJ130 Series
General Purpose Relay SPDT (1 Form C) 12VDC Coil Through Hole
