SRR1210A-180M

Active

Bourns Inc.

SURFACE MOUNT POWER INDUCTOR, AEC-Q200 SRR1210A SERIES, 18 H, 20%, SHIELDED, 0.035 OHM, 5.5 A

Search across all available documentation for this part.

Active

Bourns Inc.

SURFACE MOUNT POWER INDUCTOR, AEC-Q200 SRR1210A SERIES, 18 H, 20%, SHIELDED, 0.035 OHM, 5.5 A

Technical Specifications

Parameters and characteristics for this part

Part	Package / Case	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Inductance	Q @ Freq	Shielding	Material - Core	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Current - Saturation (Isat)	Current Rating (Amps)	Frequency - Self Resonant	Tolerance	Ratings	DC Resistance (DCR) [Max]	DC Resistance (DCR)
Bourns Inc. SRR1210A-180M	Nonstandard	0.472 in	0.472 "	12 mm	12 mm	125 °C	-40 °C	Surface Mount	18 µH	2.52 MHz 13	Shielded	Ferrite	0.394 in	10 mm	5.1 A	5.5 Amps	8 MHz	20 %	AEC-Q200	35 mOhm
Bourns Inc. SRR1210A-4R7Y	Nonstandard	0.472 in	0.472 "	12 mm	12 mm	125 °C	-40 °C	Surface Mount	4.7 ÁH	7.96 MHz 8	Shielded	Ferrite	0.394 in	10 mm	9.6 A	8.5 A	35 MHz	30 %	AEC-Q200		12 mOhm
Bourns Inc. SRR1210A-220M	Nonstandard	0.472 in	0.472 "	12 mm	12 mm	125 °C	-40 °C	Surface Mount	22 µH	2.52 MHz 16	Shielded	Ferrite	0.394 in	10 mm	4.5 A	5.2 A	8 MHz	20 %	AEC-Q200	38 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

18 µH Shielded Inductor 5.5 A 35mOhm Max Nonstandard
