1917121

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 3 POS 7.62MM PITCH PLUG 24-12 AWG SCREW

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 3 POS 7.62MM PITCH PLUG 24-12 AWG SCREW

Technical Specifications

Parameters and characteristics for this part

Specification	1917121

Color	Black
Contact Mating Finish	Tin
Current - IEC	12 A
Features	Retention Latches (Wire Side), Mating Flange
Insulation Height	1.024 "
Insulation Height	26.01 mm
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Pitch [x]	0.3 in
Pitch [x]	7.62 mm
Plug Wire Entry	90 °
Positions Per Level	3
Screw Size	M3
Termination Style	Screw - Rising Cage Clamp
Torque - Screw [Max]	0.6 Nm
Torque - Screw [Max]	5.3 Lb-In
Torque - Screw [Min]	4.4 Lb-In
Torque - Screw [Min]	0.5 Nm
Type	Plug, Female Sockets
Voltage - IEC	500 V
Wire Gauge or Range - AWG [Max]	30 AWG
Wire Gauge or Range - AWG [Min]	12 AWG
Wire Gauge or Range - mm² [Max]	2.5 mm²
Wire Gauge or Range - mm² [Min]	0.2 mm²
Wire Strip Length	7 mm

Pluggable Terminal Blocks 12 Pos 7.5mm pitch Plug 24-12 AWG Screw

Part	Pitch [x]	Pitch [x]	Features	Screw Size	Contact Mating Finish	Mounting Type	Voltage - IEC	Number of Levels	Positions Per Level	Wire Strip Length	Insulation Height	Insulation Height	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Color	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Current - IEC	Termination Style	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Type	Plug Wire Entry	Wire Gauge or Range - mm˛ [Min]	Wire Gauge or Range - mm˛ [Max]	Number of Positions	Voltage - UL	Housing Material	Material Flammability Rating
Phoenix Contact 1917121	0.3 in	7.62 mm	Mating Flange Retention Latches (Wire Side)	M3	Tin	Free Hanging (In-Line)	500 V	1	3	7 mm	1.024 "	26.01 mm	0.2 mm²	2.5 mm²	Black	30 AWG	12 AWG	12 A	Screw - Rising Cage Clamp	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Plug Female Sockets	90 °
Phoenix Contact 1737806	0.295 in	7.5 mm	Retention Latches (Wire Side)	M3	Tin	Free Hanging (In-Line)	1 kV	1	12	7 mm	1.024 "	26.01 mm			Green	30 AWG	12 AWG	12 A	Screw - Rising Cage Clamp	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	Plug Female Sockets	90 °	0.2 mm˛	2.5 mm˛	12	300 V	Polyamide (PA) Nylon	UL94 V-0

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 12 Pos 7.5mm pitch Plug 24-12 AWG Screw
