7087-4

Active

BRADY

B946 7087-4 BLK/YEL STY-4

Search across all available documentation for this part.

Active

BRADY

B946 7087-4 BLK/YEL STY-4

Technical Specifications

Parameters and characteristics for this part

Specification	7087-4

Application Specifics	Water Fluids
Applications	General
Arrangement	Text Only
Color - Background	Yellow
Color - Legend	Black
Features	Chemical Resistant, Weather Resistant, Abrasion Resistant
Language	English
Legend (Symbol Only)	False
Legend (Text)	Domestic Hot Water
Length	177.8 mm
Length	7 in
Location	Outdoor
Material - Body	Vinyl
Mounting Type	Adhesive
Outside Pipe Diameter (Max) [Max] [diameter]	19.05 mm
Outside Pipe Diameter (Max) [Max] [diameter]	3/4
Outside Pipe Diameter (Max) [Max] [diameter]	0.75 "
Outside Pipe Diameter (Min) [Min] [diameter]	2.375 in
Outside Pipe Diameter (Min) [Min] [diameter]	60.33 mm
Print Type	Pre-Printed
Shape	Rectangle
Width [x]	1.125 in
Width [x]	28.58 mm

Part	Mounting Type	Print Type	Color - Background	Color - Legend	Application Specifics	Outside Pipe Diameter (Min) [Min] [diameter]	Outside Pipe Diameter (Min) [Min] [diameter]	Length	Length	Applications	Legend (Symbol Only)	Features	Language	Material - Body	Location	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Legend (Text)	Shape	Arrangement	Width [x]	Width [x]	Outside Pipe Diameter (Max) [diameter]	Outside Pipe Diameter (Max) [diameter]	Width	Width	Width
BRADY 7087-4	Adhesive	Pre-Printed	Yellow	Black	Water Fluids	2.375 in	60.33 mm	177.8 mm	7 in	General		Abrasion Resistant Chemical Resistant Weather Resistant	English	Vinyl	Outdoor	19.05 mm	3/4	0.75 "	Domestic Hot Water	Rectangle	Text Only	1.125 in	28.58 mm
BRADY 7087-1	Adhesive	Pre-Printed	Yellow	Black	Water Fluids	7.875 in	200.03 mm	355.6 mm	14 in	Pipe		Chemical Resistant Oil Resistant Water Resistant	English	Vinyl	Outdoor				Domestic Hot Water	Rectangle	Text Only			2.5 "	63.5 mm	2 1/4"	2.25 in	57.15 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 4.37

General part information

B946 7087-4 BLK/YEL STY-4

Technical documentation and resources
