TR9CA8000LCPIM(R6B)

Active

GlobTek, Inc.

AC/DC DESKTOP ADAPTER 5V 40W

Search across all available documentation for this part.

Active

GlobTek, Inc.

AC/DC DESKTOP ADAPTER 5V 40W

Technical Specifications

Parameters and characteristics for this part

Specification	TR9CA8000LCPIM(R6B)

Applications	Household Appliances, ITE (Commercial), Medical
Approval Agency	CE, ETL, UL, CCC, cULus, NOM, FCC, BSMI, UKRSepro, LPS, cETLus, PSE, VCCI, CB, RCM, S-Mark, EAC
Cord Length	1.2 m
Cord Length	47.2 in
Current - Output (Max) [Max]	8 A
Efficiency	Level VI
Form	Desktop (Class I)
Input Connector	IEC 320-C14
Input Type	Cord
No Load Power Consumption [Max]	75 mW
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	-20 C
Output Connector	Barrel Plug
Output Connector [diameter]	2.5 mm, 5.5 mm
Output Connector [z]	11.5 mm
Polarization	Positive Center
Power (Watts)	40 W
Region Utilized	International
Size / Dimension [x]	4.63 in
Size / Dimension [x]	117.5 mm
Size / Dimension [y]	2.11 in
Size / Dimension [y]	53.5 mm
Size / Dimension [z]	1.35 "
Size / Dimension [z]	34.2 mm
Standard Number	1310, 60950-1, 60335-1, 62368-1, 60601-1-2, 60601-1-11
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Output	5 V

Part	Cord Length	Cord Length	Current - Output (Max) [Max]	Power (Watts)	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Applications	Approval Agency	Voltage - Input [Min]	Voltage - Input [Max]	Standard Number	Input Type	Form	Region Utilized	Efficiency	No Load Power Consumption [Max]	Polarization	Output Connector [diameter]	Output Connector [z]	Output Connector	Operating Temperature [Min]	Operating Temperature [Max]	Input Connector	Voltage - Output
GlobTek, Inc. TR9CA8000LCPIM(R6B)	1.2 m	47.2 in	8 A	40 W	1.35 "	34.2 mm	2.11 in	4.63 in	117.5 mm	53.5 mm	Household Appliances ITE (Commercial) Medical	BSMI CB CCC CE cETLus cULus EAC ETL FCC LPS NOM PSE RCM S-Mark UKRSepro UL VCCI	90 VAC	264 VAC	1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1	Cord	Desktop (Class I)	International	Level VI	75 mW	Positive Center	2.5 mm 5.5 mm	11.5 mm	Barrel Plug	-20 C	40 °C	IEC 320-C14	5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5V 40 W AC/DC External Desktop (Class I) Adapter Cord (Sold Separately) Input
