DAH1PPAAR04A

Active

Amphenol CONEC

DSUB GENDER CHANGER HD15M HD15M

Search across all available documentation for this part.

Active

Amphenol CONEC

DSUB GENDER CHANGER HD15M HD15M

Technical Specifications

Parameters and characteristics for this part

Specification	DAH1PPAAR04A

Connector Style	Gender Changer
Contact Finish	Gold
Convert From (Adapter End)	15 HD, Male, D-Sub
Convert To (Adapter End)	D-Sub, Male, 15 HD
Current Rating (Amps)	3 A
Features	Grounding Indents
Housing Color	Yellow
Includes	1 Connector, 2 Jack Screws
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Rows	3
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C

Part	Number of Rows	Current Rating (Amps)	Connector Style	Housing Color	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish	Includes	Convert From (Adapter End)	Convert To (Adapter End)	Features	Material Flammability Rating	Mounting Type
Amphenol CONEC DAH1PPAAR04A	3	3 A	Gender Changer	Yellow	105 ░C	-55 °C	Gold	1 Connector 2 Jack Screws	15 HD D-Sub Male	15 HD D-Sub Male	Grounding Indents	UL94 V-0	Free Hanging (In-Line)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Adapter Connector D-Sub, 15 HD, Male To D-Sub, 15 HD, Male Free Hanging (In-Line)
