Q-3E054000D.75M

Active

Amphenol Custom Cable

CBL ASSY SMA-TNC PLUG-PLG 29.53"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-3E054000D.75M

1st Connector	SMA Plug
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	TNC Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	LMR 195
Color	Black
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length	29.53 "
Length	750 mm
Overall Impedance	50 Ohms
Style	SMA to TNC

Q-3E0540 Series

Part	2nd Contact Gender	Cable Type	2nd Connector	Length	Length	1st Connector	Cable Impedance	Overall Impedance	Connector Impedance	1st Contact Gender	Style	Features	Color	2nd Connector Mounting Type	Frequency - Max [Max]	1st Connector Mounting Type	Length [x]	Length [x]	Length
Amphenol Custom Cable Q-3E054000D.75M	Male	LMR 195	TNC Plug	29.53 "	750 mm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)
Amphenol Custom Cable Q-3E054000D036I	Male	LMR 195	TNC Plug	36 in	91.44 cm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)
Amphenol Custom Cable Q-3E054000D006I	Male	LMR 195	TNC Plug	6 in	152.4 mm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)
Amphenol Custom Cable Q-3E054000D0.5M	Male	LMR 195	TNC Plug	19.69 "	50 cm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)
Amphenol Custom Cable Q-3E054000D.25M	Male	LMR 195	TNC Plug			SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)	9.843 "	250 mm
Amphenol Custom Cable Q-3E054000D048I	Male	LMR 195	TNC Plug	48 in	1200 mm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)			4 ft
Amphenol Custom Cable Q-3E054000D009I	Male	LMR 195	TNC Plug	9 "	228.6 mm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)
Amphenol Custom Cable Q-3E054000D012I	Male	LMR 195	TNC Plug	12 "	304.8 mm	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)
Amphenol Custom Cable Q-3E054000D060I	Male	LMR 195	TNC Plug	5 '	1.5 m	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)			5 ft
Amphenol Custom Cable Q-3E054000D072I	Male	LMR 195	TNC Plug	72 in	1.8 m	SMA Plug	50 Ohms	50 Ohms	50 Ohms	Male	SMA to TNC	Shielded	Black	Free Hanging (In-Line)	6000 MHz	Free Hanging (In-Line)			6 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 83.06
		25	$ 81.44
		50	$ 79.82
		100	$ 78.20
		250	$ 76.58

Description

General part information

Q-3E0540 Series

Cable Assembly Coaxial SMA to TNC LMR 195 29.53" (750.00mm)
