ALF80C751EH450

Active

KEMET

ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 25V 82000UF 105C 20% 9000HRS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsALF80C751EH450 Spec KEM_A4085_ALF80.pdf +3

ALF80C751EH450

Active

KEMET

ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 25V 82000UF 105C 20% 9000HRS

Deep-Dive with AI

DocumentsALF80C751EH450 Spec KEM_A4085_ALF80.pdf +3

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ALF80C751EH450

Applications	General Purpose
Capacitance	750 µF
ESR (Equivalent Series Resistance)	180.8 mOhm
Height - Seated (Max) [Max] [z]	62 mm
Height - Seated (Max) [Max] [z]	2.441 in
Impedance	106 mOhms
Lead Spacing	22.5 mm
Lead Spacing	0.886 in
Lifetime @ Temp.	9000 Hrs
Mounting Type	Through Hole, Press-Fit
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Press-Fit - 4 Lead
Polarization	Polar
Ripple Current @ High Frequency	9.23 A
Ripple Current @ Low Frequency	3.86 A
Size / Dimension [diameter]	1.575 "
Size / Dimension [diameter]	40 mm
Tolerance	20 %
Voltage - Rated	450 V

ALF80C Series

Part	Operating Temperature [Min]	Operating Temperature [Max]	ESR (Equivalent Series Resistance)	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Ripple Current @ Low Frequency	Lifetime @ Temp.	Package / Case	Ripple Current @ High Frequency	Lead Spacing	Lead Spacing	Impedance	Applications	Polarization	Capacitance	Tolerance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET ALF80C751EH450	-40 °C	105 ░C	180.8 mOhm	450 V	1.575 "	40 mm	Through Hole Press-Fit	3.86 A	9000 Hrs	Radial Can - Press-Fit - 4 Lead	9.23 A	22.5 mm	0.886 in	106 mOhms	General Purpose	Polar	750 µF	20 %	62 mm	2.441 in
KEMET ALF80C823EH025	-40 °C	105 ░C	20.15 mOhm	25 VDC	1.575 "	40 mm	Through Hole Press-Fit	11.85 A	9000 Hrs	Radial Can - Press-Fit - 4 Lead	13.05 A	22.5 mm	0.886 in	18 mOhms	General Purpose	Polar	82000 µF	20 %	62 mm	2.441 in
KEMET ALF80C272EL250	-40 °C	105 ░C	72.08 mOhm	250 V	1.575 "	40 mm	Through Hole Press-Fit	6.42 A	9000 Hrs	Radial Can - Press-Fit - 5 Lead	11.5 A	22.5 mm	0.886 in	45 mOhms	General Purpose	Polar	2700 µF	20 %	82 mm	3.228 in
KEMET ALF80C123DF063	-40 °C	105 ░C	33.9 mOhm	63 V	1.378 in	35 mm	Through Hole Press-Fit	7.99 A	8000 Hrs	Radial Can - Press-Fit - 4 Lead	10.62 A	22.5 mm	0.886 in	26 mOhms	General Purpose	Polar	12000 µF	20 %	52 mm	2.047 in
KEMET ALF80C132EL400	-40 °C	105 ░C	100.6 mOhm	400 V	1.575 "	40 mm	Through Hole Press-Fit	5.07 A	9000 Hrs	Radial Can - Press-Fit - 5 Lead	11.34 A	22.5 mm	0.886 in	54 mOhms	General Purpose	Polar	1300 µF	20 %	82 mm	3.228 in
KEMET ALF80C241DC450	-40 °C	105 ░C	541.2 mOhm	450 V	1.378 in	35 mm	Through Hole Press-Fit	1.81 A	8000 Hrs	Radial Can - Press-Fit - 4 Lead	5.09 A	22.5 mm	0.886 in	311 mOhms	General Purpose	Polar	240 µF	20 %	37 mm	1.457 in
KEMET ALF80C112EH350	-40 °C	105 ░C	131.8 mOhm	350 V	1.575 "	40 mm	Through Hole Press-Fit	4.26 A	9000 Hrs	Radial Can - Press-Fit - 4 Lead	9.52 A	22.5 mm	0.886 in	71 mOhms	General Purpose	Polar	1100 µF	20 %	62 mm	2.441 in
KEMET ALF80C102DF250	-40 °C	105 ░C	178.2 mOhm	250 V	1.378 in	35 mm	Through Hole Press-Fit	3.46 A	8000 Hrs	Radial Can - Press-Fit - 4 Lead	7.52 A	22.5 mm	0.886 in	106 mOhms	General Purpose	Polar	1000 µF	20 %	52 mm	2.047 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 18.62
		10	$ 17.23
Newark	Each	1	$ 19.72
		10	$ 18.34
		25	$ 17.42
		50	$ 16.50
		100	$ 16.20
		250	$ 15.90
		500	$ 15.58

Description

General part information

ALF80C Series

750 µF 450 V Aluminum Electrolytic Capacitors Radial, Can - Press-Fit - 4 Lead 180.8mOhm @ 100Hz 9000 Hrs @ 105°C
