AME10-15DCJZ

Active

aimtec

AC/DC CONVERTER +/-15V 11W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AME10-15DCJZ

Active

aimtec

AC/DC CONVERTER +/-15V 11W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AME10-15DCJZ

Applications	ITE (Commercial)
Approval Agency	CE, cURus
Current - Output (Max) [Max]	350 mA
Current - Output (Max) [Min]	350 mA
Efficiency	81 %
Features	Universal Input
Line Regulation	1.5 %
Load Regulation	2 %
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Package / Case	8-DIP Module, 6 Leads
Power (Watts)	11 W
Size / Dimension [x]	2.17 "
Size / Dimension [x]	55 mm
Size / Dimension [y]	45 mm
Size / Dimension [y]	1.77 "
Size / Dimension [z]	0.83 in
Size / Dimension [z]	21 mm
Type	Enclosed
Voltage - Input [Max]	370 VDC, 264 VAC
Voltage - Input [Min]	85 VAC, 120 VDC
Voltage - Output 1	15 V
Weight	80 g
Weight	0.176 lb

AME10 Series

Part	Efficiency	Voltage - Input [Min]	Voltage - Input [Max]	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Power (Watts)	Package / Case	Number of Outputs	Approval Agency	Voltage - Output 1	Current - Output (Max) [Max]	Load Regulation	Line Regulation	Applications	Type	Features	Weight	Weight	Current - Output (Max)	Current - Output (Max)	Standard Number	Current - Output (Max) [Min]	Current - Output (Max)
aimtec AME10-12SCJZ	80 %	85 VAC 120 VDC	264 VAC 370 VDC	Through Hole	-25 °C	70 °C	0.83 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	11 W	5 Leads 8-DIP Module	1	CE cURus	12 V	900 mA	1 %	0.5 %	ITE (Commercial)	Enclosed	Universal Input	80 g	0.176 lb
aimtec AME10-524DCVZ	80 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	10 W	8-DIP Module	2		5 V				ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb	200 mA	1 A	62368-1
aimtec AME10-15DCVZ-B	81 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	10 W	8-DIP Module	2		15 V	350 mA	2 %	1.5 %	ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb			62368-1	350 mA
aimtec AME10-515DCVZ-B	79 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	10 W	8-DIP Module	2		5 V				ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb	200 mA	1.4 A	62368-1
aimtec AME10-505DCVZ	75 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	10 W	8-DIP Module	2		5 V				ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb	200 mA	1.8 A	62368-1
aimtec AME10-15DCJZ	81 %	85 VAC 120 VDC	264 VAC 370 VDC	Through Hole	-25 °C	70 °C	0.83 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	11 W	8-DIP Module 6 Leads	2	CE cURus	15 V	350 mA	2 %	1.5 %	ITE (Commercial)	Enclosed	Universal Input	80 g	0.176 lb				350 mA
aimtec AME10-512TCVZ	75 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	9.8 W	8-DIP Module	3		5 V				ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb	200 mA	1 A	62368-1		200 mA
aimtec AME10-15DCVZ	81 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	10 W	8-DIP Module	2		15 V	350 mA	2 %	1.5 %	ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb			62368-1	350 mA
aimtec AME10-515TCVZ	75 %	85 VAC 100 V	264 VAC 370 VDC	Through Hole			0.82 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	11 W	8-DIP Module	3		5 V				ITE (Commercial)	Enclosed	Universal Input	75 g	0.165 lb		200 mA 900 mA	62368-1
aimtec AME10-524DCJZ	81 %	85 VAC 120 VDC	264 VAC 370 VDC	Through Hole	-25 °C	70 °C	0.83 in	21 mm	2.17 "	55 mm	45 mm	1.77 "	9.8 W	8-DIP Module 7 Leads	2	CE cURus	5 V		2 %	1.5 %	ITE (Commercial)	Enclosed	Universal Input	80 g	0.176 lb	200 mA	1 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

AME10 Series

Enclosed AC DC Converters 2 Output 15V 350mA, 350mA 85 ~ 264 VAC, 120 ~ 370 VDC Input

Documents

Technical documentation and resources
