TFR04PH10

Active

ITT Cannon, LLC

CONN PLUG HSG 4POS 5.08MM

Search across all available documentation for this part.

Active

ITT Cannon, LLC

CONN PLUG HSG 4POS 5.08MM

Technical Specifications

Parameters and characteristics for this part

Specification	TFR04PH10

Color	Gray
Connector Type	Plug
Contact Termination	Crimp and Solder
Contact Type	Male or Female
Fastening Type	Latch Lock
Features	Strain Relief, Flame Retardant, Hood
Insulation Material	Polyamide (PA), Nylon
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	4
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Pitch [x]	0.2 in
Pitch [x]	5.08 mm

Part	Contact Termination	Fastening Type	Features	Operating Temperature [Max]	Operating Temperature [Min]	Note	Insulation Material	Number of Rows	Connector Type	Mounting Type	Number of Positions	Color	Pitch [x]	Pitch [x]	Contact Type	Accessory Type	For Use With/Related Products
ITT Cannon, LLC TFR04PA10	Crimp and Solder	Latch Lock	Flame Retardant	105 ░C	-55 °C	Contacts Not Included	Nylon Polyamide (PA)	1	Plug	Free Hanging (In-Line)	4	Gray	0.2 in	5.08 mm	Male or Female
ITT Cannon, LLC TFR04AH10			Flame Retardant								4					Hood and Strain Relief	Trident Rectangular Plugs
ITT Cannon, LLC TFR04PH10	Crimp and Solder	Latch Lock	Flame Retardant Hood Strain Relief	105 ░C	-55 °C	Contacts Not Included	Nylon Polyamide (PA)	1	Plug	Free Hanging (In-Line)	4	Gray	0.2 in	5.08 mm	Male or Female

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 6.69
Newark	Each	100	$ 5.62
		250	$ 5.52

General part information

4 Rectangular Connectors - Housings Plug Gray 0.200" (5.08mm)
