55.34.8.024.0050

Active

Finder Relays, Inc.

RELAY GEN PURPOSE 4PDT 7A 24V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

55.34.8.024.0050

Active

Finder Relays, Inc.

RELAY GEN PURPOSE 4PDT 7A 24V

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	55.34.8.024.0050

Approval Agency	cURus, VDE, CE, UKCA, CSA, CCC, RINA, ENEC, EAC
Coil Current	53 mA
Coil Resistance	190 Ohms
Coil Type	Non Latching
Coil Voltage	24 VAC
Contact Form	4PDT (4 Form C)
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	7 A
Features	Test Button, Lighted Indicator
Load - Max Switching	1750 VA
Mounting Type	Socketable
Must Operate Voltage	19.2 VAC
Must Release Voltage	4.8 VAC
Operate Time	9 ms
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Relay Type	General Purpose
Release Time	5 ms
Switching Voltage	250 VAC
Termination Style	Plug In

55.34.8 Series

Part	Load - Max Switching	Relay Type	Operating Temperature [Max]	Operating Temperature [Min]	Contact Form	Contact Rating (Current)	Switching Voltage	Release Time	Termination Style	Must Release Voltage	Coil Type	Must Operate Voltage	Contact Material	Coil Resistance	Mounting Type	Operate Time	Coil Voltage	Approval Agency	Features	Coil Current
Finder Relays, Inc. 55.34.8.048.0040	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	9.6 VAC	Non Latching	38.4 VAC	Silver Nickel (AgNi)	770 Ohms	Socketable	9 ms	48 VAC/DC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE
Finder Relays, Inc. 55.34.8.110.5030	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	22 VAC	Non Latching	88 VAC/DC	Gold (Au) Silver Nickel (AgNi)	3.94 kOhms	Socketable	9 ms	110 VAC/DC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Lighted Indicator
Finder Relays, Inc. 55.34.8.120.5030	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	24 VAC	Non Latching	96 VAC	Gold (Au) Silver Nickel (AgNi)	4700 Ohms	Socketable	9 ms	120 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Lighted Indicator	12 mA
Finder Relays, Inc. 55.34.8.024.0000	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	4.8 VAC	Non Latching	19.2 VAC	Silver Nickel (AgNi)	190 Ohms	Socketable	9 ms	24 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE		53 mA
Finder Relays, Inc. 55.34.8.240.0040	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	48 VAC	Non Latching	192 VAC	Silver Nickel (AgNi)	19.1 kOhms	Socketable	9 ms	240 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE		5.3 mA
Finder Relays, Inc. 55.34.8.024.5050	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	4.8 VAC	Non Latching	19.2 VAC	Gold (Au) Silver Nickel (AgNi)	190 Ohms	Socketable	9 ms	24 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Lighted Indicator Test Button	53 mA
Finder Relays, Inc. 55.34.8.120.5050	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	24 VAC	Non Latching	96 VAC	Gold (Au) Silver Nickel (AgNi)	4700 Ohms	Socketable	9 ms	120 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Lighted Indicator Test Button	12 mA
Finder Relays, Inc. 55.34.8.024.0050	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	4.8 VAC	Non Latching	19.2 VAC	Silver Nickel (AgNi)	190 Ohms	Socketable	9 ms	24 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Lighted Indicator Test Button	53 mA
Finder Relays, Inc. 55.34.8.110.0050	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	22 VAC	Non Latching	88 VAC/DC	Silver Nickel (AgNi)	3.94 kOhms	Socketable	9 ms	110 VAC/DC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	Lighted Indicator Test Button
Finder Relays, Inc. 55.34.8.120.5000	1750 VA	General Purpose	85 °C	-40 °C	4PDT (4 Form C)	7 A	250 VAC	5 ms	Plug In	24 VAC	Non Latching	96 VAC	Gold (Au) Silver Nickel (AgNi)	4700 Ohms	Socketable	9 ms	120 VAC	CCC CE CSA cURus EAC ENEC RINA UKCA VDE		12 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 13.87
		10	$ 12.12
		25	$ 11.48
		50	$ 11.03
		100	$ 10.59
		250	$ 10.03
		500	$ 9.63
		1000	$ 9.25

Description

General part information

55.34.8 Series

General Purpose Relay 4PDT (4 Form C) 24VAC Coil Socketable
