DC22.9121.111

Active

SCHURTER Inc.

CONNECTOR: AC SUPPLY; SOCKET; MALE; 10A; 250VAC; C14 (E); IEC 60320

Search across all available documentation for this part.

Active

SCHURTER Inc.

CONNECTOR: AC SUPPLY; SOCKET; MALE; 10A; 250VAC; C14 (E); IEC 60320

Technical Specifications

Parameters and characteristics for this part

Specification	DC22.9121.111

Accomodates a Fuse	False
Approval Agency	ENEC, cULus
Connector Style	IEC 320-C14
Connector Type	Receptacle, Male Blades - Module
Current Rating - Appliance Inlet	10 A
Current Rating - Filter	10 A
Features	Shielded
Filter Type	Filtered (EMI, RFI) - Commercial
Ingress Protection	IP40
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Flange, Through Hole
Panel Cutout Dimensions [x]	30.4 mm
Panel Cutout Dimensions [y]	34.4 mm
Panel Thickness	0.157 in
Panel Thickness	4 mm
Switch Features	Switch On-Off
Termination	0.25 in
Termination	6.3 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet	250 VAC

Part	Filter Type	Current Rating - Appliance Inlet	Voltage Rating - Appliance Inlet	Approval Agency	Material Flammability Rating	Current Rating - Filter	Panel Thickness	Panel Thickness	Features	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Accomodates a Fuse	Connector Style	Termination	Termination	Termination	Mounting Type	Ingress Protection	Connector Type	Switch Features
SCHURTER Inc. DC22.9121.111	Filtered (EMI RFI) - Commercial	10 A	250 VAC	cULus ENEC	UL94 V-0	10 A	0.157 in	4 mm	Shielded	30.4 mm	34.4 mm		IEC 320-C14	0.25 in	6.3 mm	Quick Connect	Panel Mount Flange Through Hole	IP40	Receptacle Male Blades - Module	Switch On-Off

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	40	$ 46.52
TME	N/A	20	$ 32.12

General part information

Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange; Through Hole
