TTN2.00SV50

Active

Techflex

SLEEVING 2" ID 50' SILVER

Search across all available documentation for this part.

Active

Techflex

SLEEVING 2" ID 50' SILVER

Technical Specifications

Parameters and characteristics for this part

Specification	TTN2.00SV50

Abrasion Protection	Abrasion Resistant
Color	Silver
Diameter - Inside [diameter]	2 in
Diameter - Inside [diameter]	50.8 mm
Diameter - Outside [diameter]	52.07 mm
Diameter - Outside [diameter]	2.05 "
Features	Clean Cut, Chemical Resistant
Heat Protection	Flame Retardant, Heat Resistant
Length	15.24 m
Length [x]	50 ft
Liquid Protection	Gasoline Resistant
Material	Halogen Free, Fiberglass, Aluminized
Material Flammability Rating	Non Flammable
Operating Temperature [Max]	255 °C
Operating Temperature [Min]	-60 °C
Type	Sleeving, Insulated
Type Attributes	Convoluted - Braided
Wall Thickness [custom]	0.025 in
Wall Thickness [custom]	0.64 mm

Part	Type Attributes	Material Flammability Rating	Color	Liquid Protection	Material	Heat Protection	Diameter - Inside [diameter]	Diameter - Inside [diameter]	Abrasion Protection	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Operating Temperature [Min]	Operating Temperature [Max]	Features	Wall Thickness [custom]	Wall Thickness [custom]	Type	Length	Length [x]
Techflex TTN2.00SV50	Convoluted - Braided	Non Flammable	Silver	Gasoline Resistant	Aluminized Fiberglass Halogen Free	Flame Retardant Heat Resistant	2 in	50.8 mm	Abrasion Resistant	52.07 mm	2.05 "	-60 °C	255 °C	Chemical Resistant Clean Cut	0.025 in	0.64 mm	Sleeving Insulated	15.24 m	50 ft

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 209.38

General part information

Silver Fiberglass, Aluminized, Halogen Free Convoluted - Braided Sleeving, Insulated 2.000" (50.80mm) 50.00' (15.24m)
