446-87-226-41-036101

Active

PRECI-DIP SA

CONN SOCKET 26POS 0.1 GOLD PCB

Deep-Dive with AI

Search across all available documentation for this part.

446-87-226-41-036101

Active

PRECI-DIP SA

CONN SOCKET 26POS 0.1 GOLD PCB

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	446-87-226-41-036101

Connector Type	Socket
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	Flash
Contact Length - Post	2.79 mm
Contact Length - Post [x]	0.11 in
Contact Material	Beryllium Copper
Contact Shape	Circular
Contact Type	Female Socket
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	2.95 mm
Insulation Height	0.116 in
Insulation Material	Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	26
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Termination	Solder, Press-Fit

446-87 Series

Part	Contact Finish - Post	Termination	Contact Finish Thickness - Mating	Number of Positions Loaded	Contact Material	Insulation Material	Number of Rows	Current Rating (Amps)	Contact Shape	Number of Positions	Mounting Type	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Color	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Pitch - Mating	Pitch - Mating	Contact Type	Fastening Type	Insulation Height	Insulation Height	Connector Type	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Contact Length - Post
PRECI-DIP SA 446-87-270-41-035101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	70	Through Hole	0.15 in	3.81 mm	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.173 in	4.4 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold
PRECI-DIP SA 446-87-258-41-035101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	58	Through Hole	0.15 in	3.81 mm	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.173 in	4.4 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold
PRECI-DIP SA 446-87-204-41-035101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	4	Through Hole	0.15 in	3.81 mm	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.173 in	4.4 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold
PRECI-DIP SA 446-87-208-41-036101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	8	Through Hole	0.11 in		Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.116 in	2.95 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold	2.79 mm
PRECI-DIP SA 446-87-236-41-035101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	36	Through Hole	0.15 in	3.81 mm	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.173 in	4.4 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold
PRECI-DIP SA 446-87-218-41-035101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	18	Through Hole	0.15 in	3.81 mm	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.173 in	4.4 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold
PRECI-DIP SA 446-87-226-41-036101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	26	Through Hole	0.11 in		Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.116 in	2.95 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold	2.79 mm
PRECI-DIP SA 446-87-254-41-036101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	54	Through Hole	0.11 in		Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.116 in	2.95 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold	2.79 mm
PRECI-DIP SA 446-87-242-41-035101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	42	Through Hole	0.15 in	3.81 mm	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.173 in	4.4 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold
PRECI-DIP SA 446-87-218-41-036101	Tin	Press-Fit Solder	Flash	All	Beryllium Copper	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	2	3 A	Circular	18	Through Hole	0.11 in		Black	2.54 mm	0.1 in	0.1 in	2.54 mm	Female Socket	Push-Pull	0.116 in	2.95 mm	Socket	UL94 V-0	-55 °C	125 °C	Gold	2.79 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	250	$ 3.22

Description

General part information

446-87 Series

26 Position Socket Connector 0.100" (2.54mm) Through Hole Gold
