DD62M32S60V5X/AA

Active

Amphenol Positronic

CONN D-SUB HD PLUG 62P VERT SLDR

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

DD62M32S60V5X/AA

Active

Amphenol Positronic

CONN D-SUB HD PLUG 62P VERT SLDR

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	DD62M32S60V5X/AA

Color	Blue
Connector Style	High Density, D-Sub
Connector Type	Plug, Male Pins
Contact Finish	Gold
Contact Finish Thickness	Flash
Contact Material	Copper Alloy
Contact Type	Signal
Current Rating (Amps)	5 A
Dielectric Material	Polyester, Glass Filled
Flange Feature	Board Side, 4-40
Ingress Protection	IP67, IP65
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	62
Number of Rows	3
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Shell Size, Connector Layout	4
Termination	Solder
Voltage Rating	300 VDC

DD62M Series

Part	Ingress Protection	Number of Rows	Contact Finish	Flange Feature	Number of Positions	Connector Type	Shell Size, Connector Layout	Contact Finish Thickness	Dielectric Material	Material Flammability Rating	Voltage Rating	Color	Contact Material	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Shell Material, Finish	Current Rating (Amps)	Contact Type	Connector Style	Flange Feature [custom]	Flange Feature [custom]	Wire Gauge [Max]	Wire Gauge [Min]
Amphenol Positronic DD62M32S60V30/AA	IP65 IP67	3	Gold	4-40 Board Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole	Clear Chromate Plated Zinc Steel	5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S0V3X/AA	IP65 IP67	3	Gold	4-40 Board Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole		5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S0T20/AA	IP65 IP67	3	Gold	Female Screwlock (4-40) Mating Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole	Clear Chromate Plated Zinc Steel	5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S0V50	IP65 IP67	3	Gold	4-40 Board Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole	Clear Chromate Plated Zinc Steel	5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S0T20	IP65 IP67	3	Gold	Female Screwlock (4-40) Mating Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole	Clear Chromate Plated Zinc Steel	5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S60V5X/AA	IP65 IP67	3	Gold	4-40 Board Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole		5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S60T20/AA	IP65 IP67	3	Gold	Female Screwlock (4-40) Mating Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole	Clear Chromate Plated Zinc Steel	5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M32S0V3X	IP65 IP67	3	Gold	4-40 Board Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole		5 A	Signal	D-Sub High Density
Amphenol Positronic DD62M100E2S/AA	IP65 IP67	3	Gold		62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Crimp	-55 °C	125 °C	Free Hanging (In-Line)	Passivated Stainless Steel	5 A	Signal	D-Sub High Density	Cable Side	Male Jackscrew (4-40)	30 AWG	22 AWG
Amphenol Positronic DD62M32S60T2X	IP65 IP67	3	Gold	Female Screwlock (4-40) Mating Side	62	Male Pins Plug	4	Flash	Polyester Glass Filled	UL94 V-0	300 VDC	Blue	Copper Alloy	Solder	-55 °C	125 °C	Through Hole		5 A	Signal	D-Sub High Density

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 50.76
		10	$ 48.91
		25	$ 48.04
		50	$ 47.20

Description

General part information

DD62M Series

62 Position D-Sub, High Density Plug, Male Pins Connector
