0192690152

Active

Molex

HEATSHRINK 1" X 0.167' RED

Deep-Dive with AI

Search across all available documentation for this part.

0192690152

Active

Molex

HEATSHRINK 1" X 0.167' RED

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	0192690152

Color	Red
Features	Vibration Resistant, Adhesive Lined, Abrasion Resistant, Strain Resistant, Corrosion Resistant
Inner Diameter - Recovered [diameter]	8.13 mm
Inner Diameter - Recovered [diameter]	0.32 "
Inner Diameter - Supplied [diameter]	1 in
Inner Diameter - Supplied [diameter]	25.4 mm
Length [x]	2.01 "
Length [x]	0.167 '
Length [x]	51 mm
Material	Polyolefin (PO), Irradiated
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Recovered Wall Thickness [custom]	1.91 mm
Recovered Wall Thickness [custom]	0.075 in
Shrink Temperature	120 °C
Shrinkage Ratio [Max]	3
Shrinkage Ratio [Min]	1
Type	Tubing, Flexible

019269 Series

Dual Wall Polyolefin Heat Shrink Tubing with Adhesive Melt Liner, 6.35mm Inside Diameter (As Supplied), Black, 1.22m Length

Part	Recovered Wall Thickness	Recovered Wall Thickness	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Length	Length	Length	Type	Features	Shrink Temperature	Color	Operating Temperature [Min]	Operating Temperature [Max]	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Material	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Length	Recovered Wall Thickness [custom]	Recovered Wall Thickness [custom]	Length [x]	Length [x]	Length [x]
Molex 0192690115	1.27 mm	0.05 in	0.12 in	3.05 mm	152.4 mm	6 "	0.5 '	Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Red	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.375 in	9.53 mm
Molex 0192690077	1.19 mm	0.047 "	0.08 in	2.03 mm	25.4 mm	1 in		Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.25 in	6.35 mm	0.083 ft
Molex 0192690030	1.4 mm	0.055 in	0.157 in	3.99 mm				Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.5 in	12.7 mm
Molex 0192690064			0.32 "	8.13 mm	50.8 mm	2 "		Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	1 in	25.4 mm	0.167 '	1.91 mm	0.075 in
Molex 0192690029	1.4 mm	0.055 in	0.157 in	3.99 mm	152.4 mm	6 "	0.5 '	Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.5 in	12.7 mm
Molex 0192690075	1.4 mm	0.055 in	0.157 in	3.99 mm	76.2 mm	3 "		Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.5 in	12.7 mm	0.25 ft
Molex 0192690066								Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Clear	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated
Molex 0192690112	1.27 mm	0.05 in	0.12 in	3.05 mm	25.4 mm	1 in		Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.375 in	9.53 mm	0.083 ft
Molex 0192690076	1.19 mm	0.047 "	0.08 in	2.03 mm				Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Black	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	0.25 in	6.35 mm
Molex 0192690152			0.32 "	8.13 mm				Tubing Flexible	Abrasion Resistant Adhesive Lined Corrosion Resistant Strain Resistant Vibration Resistant	120 °C	Red	-55 °C	125 °C	1	3	Polyolefin (PO) Irradiated	1 in	25.4 mm		1.91 mm	0.075 in	2.01 "	0.167 '	51 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1000	$ 3.67

Description

General part information

019269 Series

Dual Wall Polyolefin Heat Shrink Tubing with Adhesive Melt Liner, 6.35mm Inside Diameter (As Supplied), Black, 1.22m Length

Documents

Technical documentation and resources

No documents available
