7829H-1-023LF

Active

Bourns Inc.

SWITCH ROTARY DIP SPDT 0.1A 16V

Search across all available documentation for this part.

Active

Bourns Inc.

SWITCH ROTARY DIP SPDT 0.1A 16V

Technical Specifications

Parameters and characteristics for this part

Part	Washable	Termination Style	Height Above Board	Height Above Board	Current Rating (Amps)	Mounting Type	Number of Positions	Actuator Type	Voltage Rating	Operating Temperature [Min]	Operating Temperature [Max]	Mechanical Life	Circuit	Length	Length	Actuator Level
Bourns Inc. 7829H-1-023LF		PC Pin	4.57 mm	0.18 in	100 mA	Through Hole	2	Rotary for Tool	16 VAC/DC	-55 °C	125 °C	2000 Cycles	SPDT	0.25 in	0.25 in	Raised

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Dip Switch SPDT 2 Position Through Hole Rotary for Tool Actuator 100mA 16VAC/DC

Technical documentation and resources
