ALO30F48N-SL
ActiveARTESYN / Advanced Energy
DC DC CONVERTER 3.3V 120W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ALO30F48N-SL
ActiveARTESYN / Advanced Energy
DC DC CONVERTER 3.3V 120W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ALO30F48N-SL |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 30 A |
| Efficiency | 91 % |
| Features | OTP, Remote On/Off, OVP, UVLO, OCP |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 1/8 Brick, 8-SMD Module |
| Power (Watts) | 120 W |
| Size / Dimension [x] | 2.3 in |
| Size / Dimension [x] | 58.4 mm |
| Size / Dimension [y] | 0.9 " |
| Size / Dimension [y] | 22.9 mm |
| Size / Dimension [z] | 0.31 in |
| Size / Dimension [z] | 7.9 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 36 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 100 | $ 54.14 | |
Description
General part information
ALO30F Series
Isolated Module DC DC Converter 1 Output 3.3V 30A 36V - 75V Input
