IS49NLC18160-25BLI

Active

ISSI, Integrated Silicon Solution Inc

IC DRAM 288MBIT PAR 144FCBGA

Search across all available documentation for this part.

Active

ISSI, Integrated Silicon Solution Inc

IC DRAM 288MBIT PAR 144FCBGA

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Type	Memory Size	Package / Case	Memory Format	Memory Interface	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Supplier Device Package	Access Time	Clock Frequency	Memory Organization	Supplier Device Package [x]	Supplier Device Package [y]
ISSI, Integrated Silicon Solution Inc IS49NLC18160-25BLI	1.9 V	1.7 V	Volatile	288 Mbit	144-TFBGA	DRAM	Parallel	85 °C	-40 °C	Surface Mount	144-FCBGA (11x18.5)	20 ns	400 MHz	16 M 18
ISSI, Integrated Silicon Solution Inc IS49NLC18160-33BI	1.9 V	1.7 V	Volatile	288 Mbit	144-TFBGA	DRAM	Parallel	85 °C	-40 °C	Surface Mount	144-FCBGA (11x18.5)	20 ns	300 MHz	16 M 18
ISSI, Integrated Silicon Solution Inc IS49NLC18160-25BL	1.9 V	1.7 V	Volatile	288 Mbit	144-TFBGA	DRAM	Parallel	70 °C	0 °C	Surface Mount	144-FCBGA (11x18.5)	20 ns	400 MHz	16 M 18
ISSI, Integrated Silicon Solution Inc IS49NLC18160-25BI	1.9 V	1.7 V	Volatile	288 Mbit	144-TFBGA	DRAM	Parallel	85 °C	-40 °C	Surface Mount	144-FCBGA (11x18.5)	20 ns	400 MHz	16 M 18
ISSI, Integrated Silicon Solution Inc IS49NLC18160-33WBLI	1.9 V	1.7 V	Volatile	288 Mbit	144-TFBGA	DRAM	Parallel	85 °C	-40 °C	Surface Mount	144-TWBGA	20 ns	300 MHz	16 M 18	11	18.5
ISSI, Integrated Silicon Solution Inc IS49NLC18160-33BLI	1.9 V	1.7 V	Volatile	288 Mbit	144-TFBGA	DRAM	Parallel	85 °C	-40 °C	Surface Mount	144-TWBGA	20 ns	300 MHz	16 M 18	11	18.5

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

RLDRAM 2 Memory IC 288Mbit Parallel 400 MHz 20 ns 144-FCBGA (11x18.5)

Technical documentation and resources

No documents available
