TR18RDM180-01G03 BK-BK VI

Active

Cincon Electronics Co. LTD

AC/DC WALL MOUNT ADAPTER 18V 18W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

TR18RDM180-01G03 BK-BK VI

Active

Cincon Electronics Co. LTD

AC/DC WALL MOUNT ADAPTER 18V 18W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TR18RDM180-01G03 BK-BK VI

Applications	Household Appliances, Medical
Approval Agency	TUV, CE, FCC, cURus, PSE
Cord Length	28.35 in
Cord Length	720 mm
Current - Output (Max) [Max]	1 A
Efficiency	CoC Tier 2, Level VI
Form	Wall Mount (Class II)
Input Connector	Multi-Blade
Input Type	Multi-Blade (Sold Separately)
No Load Power Consumption [Max]	75 mW
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-30 ░C
Output Connector	Barrel Plug R/A
Output Connector [diameter]	2.1 mm, 5.5 mm
Output Connector [x]	12 mm
Polarization	Positive Center
Power (Watts)	18 W
Region Utilized	International
Size / Dimension [x]	3.17 in
Size / Dimension [x]	80.4 mm
Size / Dimension [y]	1.69 in
Size / Dimension [y]	43 mm
Size / Dimension [z]	1.45 in
Size / Dimension [z]	36.9 mm
Standard Number	60335-1, 60601-1
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	80 VAC
Voltage - Output	18 V

TR18RDM Series

Part	Standard Number	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Region Utilized	Polarization	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Applications	Output Connector [diameter]	Output Connector [x]	Output Connector	Voltage - Output	Approval Agency	Power (Watts)	Input Connector	No Load Power Consumption [Max]	Cord Length	Cord Length	Voltage - Input [Max]	Voltage - Input [Min]	Efficiency	Input Type	Form	Accessory Type	For Use With/Related Products
Cincon Electronics Co. LTD TR18RDM180-01G03 BK-BK VI	60335-1 60601-1	1 A	70 °C	-30 ░C	International	Positive Center	1.69 in	1.45 in	3.17 in	36.9 mm	80.4 mm	43 mm	Household Appliances Medical	2.1 mm 5.5 mm	12 mm	Barrel Plug R/A	18 V	CE cURus FCC PSE TUV	18 W	Multi-Blade	75 mW	28.35 in	720 mm	264 VAC	80 VAC	CoC Tier 2 Level VI	Multi-Blade (Sold Separately)	Wall Mount (Class II)
Cincon Electronics Co. LTD TR18RDM-ASUE																													Interchangeable Plug Kit	TR18RDM Series Wall Adapters
Cincon Electronics Co. LTD TR18RDM120-01G03 BK-BK VI	60335-1 60601-1	1.5 A	70 °C	-30 ░C	International	Positive Center	1.69 in	1.45 in	3.17 in	36.9 mm	80.4 mm	43 mm	Household Appliances Medical	2.1 mm 5.5 mm	12 mm	Barrel Plug R/A	12 V	CE cURus FCC PSE TUV	18 W	Multi-Blade	75 mW	28.35 in	720 mm	264 VAC	80 VAC	CoC Tier 2 Level VI	Multi-Blade (Sold Separately)	Wall Mount (Class II)
Cincon Electronics Co. LTD TR18RDM090-01G03 BK-BK VI	60335-1 60601-1	2 A	70 °C	-30 ░C	International	Positive Center	1.69 in	1.45 in	3.17 in	36.9 mm	80.4 mm	43 mm	Household Appliances Medical	2.1 mm 5.5 mm	12 mm	Barrel Plug R/A	9 V	CE cURus FCC PSE TUV	18 W	Multi-Blade	75 mW	28.35 in	720 mm	264 VAC	80 VAC	CoC Tier 2 Level VI	Multi-Blade (Sold Separately)	Wall Mount (Class II)
Cincon Electronics Co. LTD TR18RDM240-01G03 BK-BK VI	60335-1 60601-1	750 mA	70 °C	-30 ░C	International	Positive Center	1.69 in	1.45 in	3.17 in	36.9 mm	80.4 mm	43 mm	Household Appliances Medical	2.1 mm 5.5 mm	12 mm	Barrel Plug R/A	24 V	CE cURus FCC PSE TUV	18 W	Multi-Blade	75 mW	28.35 in	720 mm	264 VAC	80 VAC	CoC Tier 2 Level VI	Multi-Blade (Sold Separately)	Wall Mount (Class II)
Cincon Electronics Co. LTD TR18RDM150-01G03 BK-BK VI	60335-1 60601-1	1.2 A	70 °C	-30 ░C	International	Positive Center	1.69 in	1.45 in	3.17 in	36.9 mm	80.4 mm	43 mm	Household Appliances Medical	2.1 mm 5.5 mm	12 mm	Barrel Plug R/A	15 VDC	CE cURus FCC PSE TUV	18 W	Multi-Blade	75 mW	28.35 in	720 mm	264 VAC	80 VAC	CoC Tier 2 Level VI	Multi-Blade (Sold Separately)	Wall Mount (Class II)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 15.71
		5	$ 15.24
		10	$ 14.78
		25	$ 14.04
		50	$ 13.48
		100	$ 12.54

Description

General part information

TR18RDM Series

18V 18 W AC/DC External Wall Mount (Class II) Adapter Multi-Blade (Sold Separately) Input
