NFZ32BW150HN10L
ActiveMurata Power Solutions Inc.
FERRITE BEAD 15 OHM 2SMD 1LN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NFZ32BW150HN10L
ActiveMurata Power Solutions Inc.
FERRITE BEAD 15 OHM 2SMD 1LN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NFZ32BW150HN10L |
|---|---|
| Current Rating (Max) [Max] | 1.6 A |
| DC Resistance (DCR) (Max) [Max] | 91.2 mOhm |
| Height (Max) [Max] | 0.067 " |
| Height (Max) [Max] | 1.7 mm |
| Impedance @ Frequency | 15 Ohms |
| Mounting Type | Surface Mount |
| Number of Lines | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 2-SMD, Flat Lead |
| Size / Dimension [x] | 3.2 mm |
| Size / Dimension [x] | 0.126 in |
| Size / Dimension [y] | 2.5 mm |
| Size / Dimension [y] | 0.098 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.50 | |
| Digi-Reel® | 1 | $ 0.50 | ||
| Tape & Reel (TR) | 2000 | $ 0.16 | ||
Description
General part information
NFZ32BW Series
15 Ohms @ 1 MHz 1 Ferrite Bead 2-SMD, Flat Lead 1.6A 91.2mOhm
