1041459

Active

SICK, Inc.

SENSOR THROUGH-BEAM 15M PNP

Search across all available documentation for this part.

Active

SICK, Inc.

SENSOR THROUGH-BEAM 15M PNP

Technical Specifications

Parameters and characteristics for this part

Specification	1041459

Adjustment Type	Adjustable, 5-Turn Potentiometer
Connection Method	Connector, 4POS, M12
Ingress Protection	IP69K, IP66, IP67
Light Source	Red LED
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-40 °C
Output Configuration	PNP - Dark-ON/Light-ON - Selectable
Response Time	330 µs
Sensing Distance [Max]	15 m
Sensing Distance [Max]	590.551 in
Sensing Distance [Min]	0 "
Sensing Distance [Min]	0 mm
Sensing Method	Through-Beam
Voltage - Supply [Max]	30 VDC
Voltage - Supply [Min]	10 VDC

Part	Response Time	Light Source	Ingress Protection	Sensing Method	Voltage - Supply [Max]	Voltage - Supply [Min]	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Min]	Sensing Distance [Max]	Connection Method	Operating Temperature [Min]	Operating Temperature [Max]	Output Configuration	Adjustment Type	Sensing Distance	Sensing Distance	Light Source	Cable Length	Cable Length
SICK, Inc. 1041459	330 µs	Red LED	IP66 IP67 IP69K	Through-Beam	30 VDC	10 VDC	15 m	0 "	0 mm	590.551 in	4POS Connector M12	-40 °C	60 °C	PNP - Dark-ON/Light-ON - Selectable	Adjustable 5-Turn Potentiometer
SICK, Inc. 1041462	200 µs	Red	IP67 IP69K	Through-Beam	30 VDC	10 VDC					Connector M12	-10 °C	50 °C	NPN - Dark-ON/Light-ON		0.394 in	10 mm	640 nm
SICK, Inc. 1041464	330 µs	Infrared		Through-Beam	30 VDC	10 VDC					Cable	-40 °C	60 °C	PNP	Adjustable 5-Turn Potentiometer	787.402 in	20 m		78.74 in	2 m
SICK, Inc. 1041465	330 µs	Infrared		Through-Beam	30 VDC	10 VDC					Connector M12	-40 °C	60 °C	PNP	Adjustable 5-Turn Potentiometer	787.402 in	20 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Through-Beam Optical Sensor 0" ~ 590.551" (0m ~ 15m) PNP - Dark-ON/Light-ON - Selectable
