SGR20N40LTF

Obsolete

ON Semiconductor

IGBT 400V 45W DPAK

Search across all available documentation for this part.

Obsolete

ON Semiconductor

IGBT 400V 45W DPAK

Technical Specifications

Parameters and characteristics for this part

Specification	SGR20N40LTF

Current - Collector Pulsed (Icm)	150 A
IGBT Type	Trench
Mounting Type	Surface Mount
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Package / Case	SC-63, DPAK (2 Leads + Tab), TO-252-3
Power - Max [Max]	45 W
Supplier Device Package	TO-252AA
Vce(on) (Max) @ Vge, Ic	8 V
Voltage - Collector Emitter Breakdown (Max)	400 V

Part	Voltage - Collector Emitter Breakdown (Max)	Supplier Device Package	Power - Max [Max]	Vce(on) (Max) @ Vge, Ic	Package / Case	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	IGBT Type	Current - Collector Pulsed (Icm)
ON Semiconductor SGR20N40LTF	400 V	TO-252AA	45 W	8 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	Surface Mount	150 °C	-40 °C	Trench	150 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

IGBT Trench 400 V 45 W Surface Mount TO-252AA
