Q45VR2LV W/30
ActiveBANNER ENGINEERING
RANGE: 0.08 - 9 M; INPUT: 90-250
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
Q45VR2LV W/30
ActiveBANNER ENGINEERING
RANGE: 0.08 - 9 M; INPUT: 90-250
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | Q45VR2LV W/30 |
|---|---|
| Cable Length | 354.33 in |
| Cable Length | 9 m |
| Connection Method | Cable |
| Ingress Protection | NEMA 6P, IEC IP67 |
| Light Source | Red |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | SPDT - Dark-ON/Light-ON |
| Response Time | 15 ms |
| Sensing Distance | 29.53 ft |
| Sensing Distance | 9 m |
| Sensing Method | NonPolarized, Retroreflective |
| Voltage - Supply [Max] | 250 VAC |
| Voltage - Supply [Min] | 90 VAC |
Q45V Series
| Part | Connection Method | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply [Max] | Voltage - Supply [Min] | Sensing Method | Sensing Distance | Sensing Distance | Output Configuration | Light Source | Response Time | Cable Length | Cable Length | Ingress Protection | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Max] | Sensing Distance [Min] | Adjustment Type | Sensing Distance [Max] | Sensing Distance [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
BANNER ENGINEERING | Cable | -40 °C | 70 °C | 250 VAC | 90 VAC | NonPolarized Retroreflective | 29.53 ft | 9 m | SPDT - Dark-ON/Light-ON | Red | 15 ms | 354.33 in | 9 m | NEMA 6P IEC IP67 | |||||||
BANNER ENGINEERING | Cable with Connector | -25 °C | 55 °C | 250 V 250 VAC | 12 V 24 VAC | NonPolarized Retroreflective | SPDT | Red | 15 ms | 78.74 in | 2 m | NEMA 6P IEC IP67 | 80 mm | 9000 mm | 354.33 " | 3.15 " | |||||
BANNER ENGINEERING | Cable | -25 °C | 55 °C | 250 V 250 VAC | 12 V 24 VAC | NonPolarized Retroreflective | SPDT | Red | 15 ms | 78.74 in | 2 m | NEMA 6P IEC IP67 | 9000 mm | 800 mm | Adjustable | 354.33 in | 31.5 in | ||||
BANNER ENGINEERING | Cable | -40 °C | 70 °C | 250 VAC | 90 VAC | NonPolarized Retroreflective | 29.53 ft | 9 m | Light-On/Dark-On | LED | 15 ms | 78.74 in | 2 m | NEMA 6P IEC IP67 | |||||||
BANNER ENGINEERING | Cable | -25 °C | 55 °C | 250 V 250 VAC | 12 V 24 VAC | Through-Beam | 196.85 ft | 60 m | SPDT | Infrared | 15 ms | 78.74 in | 2 m | IP67 NEMA 6P IEC IP67 | Adjustable | ||||||
BANNER ENGINEERING | Connector | -25 °C | 55 °C | 250 V 250 VAC | 12 V 24 VAC | Fiber Optic | SPDT | Infrared | 15 ms | NEMA 6P IEC IP67 | Adjustable | ||||||||||
BANNER ENGINEERING | Connector | -40 °C | 70 °C | 250 VAC | 90 VAC | Convergent | 1.496 in | 38 mm | SPDT - Dark-ON/Light-ON | Red | 15 ms | NEMA 6P IEC IP67 | |||||||||
BANNER ENGINEERING | Cable | -25 °C | 55 °C | 250 V 250 VAC | 12 V 24 VAC | Polarized Retroreflective | SPDT | Red | 15 ms | 78.74 in | 2 m | NEMA 6P IEC IP67 | 6 m | 15 cm | Adjustable | 236.22 in | 5.91 " | ||||
BANNER ENGINEERING | Connector | -25 °C | 55 °C | 250 V 250 VAC | 12 V 24 VAC | NonPolarized Retroreflective | SPDT | Red | 15 ms | NEMA 6P IEC IP67 | 9000 mm | 800 mm | Adjustable | 354.33 in | 31.5 in | ||||||
BANNER ENGINEERING | Connector | -40 °C | 70 °C | 250 VAC | 90 VAC | Red LED | 15 ms | NEMA 6P IEC IP67 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 184.00 | |
Description
General part information
Q45V Series
Retroreflective, NonPolarized Optical Sensor 29.53' (9m) SPDT - Dark-ON/Light-ON
