HRP-450-36
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 36V 450W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
HRP-450-36
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 36V 450W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | HRP-450-36 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, CE, cURus, TUV |
| Current - Output 1 | 12.5 A |
| Efficiency | 89 % |
| Features | Universal Input, Remote Sense, Adjustable Output, PFC |
| Minimum Load Required | False |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Power (Watts) | 450 W |
| Size / Dimension [x] | 8.58 " |
| Size / Dimension [x] | 218 mm |
| Size / Dimension [y] | 105 mm |
| Size / Dimension [y] | 4.13 in |
| Size / Dimension [z] | 41 mm |
| Size / Dimension [z] | 1.61 " |
| Type | Enclosed |
| Voltage - Input [Max] | 370 VDC, 264 VAC |
| Voltage - Input [Min] | 85 VAC, 120 VDC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 36 V |
HRP-450 Series
| Part | Power (Watts) | Approval Agency | Voltage - Output 1 | Features | Current - Output 1 | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Mounting Type | Number of Outputs | Applications | Voltage - Input [Min] | Voltage - Input [Max] | Minimum Load Required | Type | Efficiency | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MEAN WELL USA Inc. | 450 W | CB CE cURus TUV | 15 V | Adjustable Output PFC Remote Sense Universal Input | 30 A | 41 mm | 8.58 " | 105 mm | 218 mm | 1.61 " | 4.13 in | Chassis Mount | 1 | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | Enclosed | 89 % | 3000 V | |
MEAN WELL USA Inc. | 450 W | CB CE cURus TUV | 36 V | Adjustable Output PFC Remote Sense Universal Input | 12.5 A | 41 mm | 8.58 " | 105 mm | 218 mm | 1.61 " | 4.13 in | Chassis Mount | 1 | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | Enclosed | 89 % | 3000 V | |
MEAN WELL USA Inc. | 456 W | CB CE cURus TUV | 48 V | Adjustable Output PFC Remote Sense Universal Input | 9.5 A | 41 mm | 8.58 " | 105 mm | 218 mm | 1.61 " | 4.13 in | Chassis Mount | 1 | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | Enclosed | 3000 V | ||
MEAN WELL USA Inc. | 450 W | CB CE cURus TUV | 12 V | Adjustable Output PFC Remote Sense Universal Input | 37.5 A | 41 mm | 8.58 " | 105 mm | 218 mm | 1.61 " | 4.13 in | Chassis Mount | 1 | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | Enclosed | 88 % | 3000 V | |
MEAN WELL USA Inc. | 450 W | CB CE cURus TUV | 5 V | Adjustable Output PFC Remote Sense Universal Input | 90 A | 41 mm | 8.58 " | 105 mm | 218 mm | 1.61 " | 4.13 in | Chassis Mount | 1 | ITE (Commercial) | 85 VAC 120 VDC | 264 VAC 370 VDC | Enclosed | 83 % | 3000 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 152.64 | |
| 5 | $ 143.80 | |||
| 10 | $ 140.16 | |||
| 25 | $ 135.47 | |||
Description
General part information
HRP-450 Series
Enclosed AC DC Converters 1 Output 36V 85 ~ 264 VAC, 120 ~ 370 VDC Input
