VHV12-1.5K1000P

Active

Volgen + Furuno

DC DC CONVERTER 1500V 1.5W

Search across all available documentation for this part.

Active

Volgen + Furuno

DC DC CONVERTER 1500V 1.5W

Technical Specifications

Parameters and characteristics for this part

Specification	VHV12-1.5K1000P

Applications	ITE (Commercial)
Control Features	Active High, Enable
Current - Output (Max) [Max]	1 mA
Features	Remote On/Off, OCP, SCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max] [custom]	50 °C
Operating Temperature [Min] [custom]	-10 °C
Power (Watts)	1.5 W
Size / Dimension [x]	1.73 in
Size / Dimension [x]	44 mm
Size / Dimension [y]	0.63 in
Size / Dimension [y]	16 mm
Size / Dimension [z]	30 mm
Size / Dimension [z]	1.18 in
Type	High Voltage - Non-Isolated Module
Voltage - Input (Max) [Max]	13 V
Voltage - Input (Min) [Min]	11 V
Voltage - Output 1	1500 V

Part	Control Features	Voltage - Output 1	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Current - Output (Max) [Max]	Features	Voltage - Input (Max) [Max]	Type	Mounting Type	Applications	Voltage - Input (Min) [Min]	Power (Watts)	Number of Outputs
Volgen + Furuno VHV12-1.5K1000P	Active High Enable	1500 V	0.63 in	30 mm	1.73 in	1.18 in	16 mm	44 mm	-10 °C	50 °C	1 mA	OCP Remote On/Off SCP	13 V	High Voltage - Non-Isolated Module	Through Hole	ITE (Commercial)	11 V	1.5 W	1
Volgen + Furuno VHV12-2.0K700P	Active High Enable	2000 V	0.63 in	30 mm	1.73 in	1.18 in	16 mm	44 mm	-10 °C	50 °C	700 µA	OCP Remote On/Off SCP	13 V	High Voltage - Non-Isolated Module	Through Hole	ITE (Commercial)	11 V	1.5 W	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 155.06

General part information

High Voltage - Non-Isolated Module DC DC Converter 1 Output 1500V 1mA 11V - 13V Input
