PFUF.150.2

Active

SCHURTER Inc.

PTC RESET FUSE 6V 1.5A 1210

Search across all available documentation for this part.

Active

SCHURTER Inc.

PTC RESET FUSE 6V 1.5A 1210

Technical Specifications

Parameters and characteristics for this part

Specification	PFUF.150.2

Approval Agency	cURus, TUV
Current - Hold (Ih) (Max) [Max]	1.5 A
Current - Max [Max]	40 A
Current - Trip (It)	3 A
Mounting Type	Surface Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Concave, 1210 (3225 Metric)
Resistance - Initial (Ri) (Min) [Min]	30 mOhms
Resistance - Post Trip (R1) (Max) [Max]	110 mOhms
Size / Dimension [x]	0.127 in
Size / Dimension [x]	3.22 mm
Size / Dimension [y]	0.102 "
Size / Dimension [y]	2.58 mm
Thickness (Max) [Max]	0.025 in
Thickness (Max) [Max]	0.63 mm
Time to Trip	5 s
Type	Polymeric
Voltage - Max [Max]	6 V

Part	Current - Trip (It)	Time to Trip	Thickness (Max) [Max]	Thickness (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Resistance - Post Trip (R1) (Max) [Max]	Package / Case	Approval Agency	Voltage - Max [Max]	Current - Max [Max]	Resistance - Initial (Ri) (Min) [Min]	Current - Hold (Ih) (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Type
SCHURTER Inc. PFUF.150.2	3 A	5 s	0.025 in	0.63 mm	0.102 "	0.127 in	2.58 mm	3.22 mm	110 mOhms	1210 (3225 Metric) Concave	cURus TUV	6 V	40 A	30 mOhms	1.5 A	85 °C	-40 °C	Surface Mount	Polymeric

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Polymeric PTC Resettable Fuse 6V 1.5 A Ih Surface Mount 1210 (3225 Metric), Concave
