FLM-S21-W0

Active

Amphenol ICC (Commercial Products)

PLUG HOUSING, FLM SERIES, ZHAGA

Search across all available documentation for this part.

Active

Amphenol ICC (Commercial Products)

PLUG HOUSING, FLM SERIES, ZHAGA

Technical Specifications

Parameters and characteristics for this part

Specification	FLM-S21-W0

Connector Type	Plug Housing for Socket Contact
Fastening Type	Locking Ramp
Housing Color	White
Housing Material	Thermoplastic
Mounting Type	Free Hanging (In-Line)
Number of Positions	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch [x]	0.11 in
Pitch [x]	2.8 mm
Style	Cable/Wire to Cable/Wire
Termination	Crimp

Part	Connector Type	Style	Termination	Housing Color	Pitch [x]	Pitch [x]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Fastening Type	Number of Positions	Housing Material
Amphenol ICC (Commercial Products) FLM-S21-W0	Plug Housing for Socket Contact	Cable/Wire to Cable/Wire	Crimp	White	0.11 in	2.8 mm	-40 °C	105 ░C	Free Hanging (In-Line)	Locking Ramp	2	Thermoplastic

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	500	$ 0.98

General part information

SSL Connector 2 Position Plug Housing for Socket Contact Cable/Wire to Cable/Wire 0.110" (2.80mm) Crimp

Technical documentation and resources
