PWC-3.3S
ActiveAstrodyne TDI
AC/DC CONVERTER 3.3V 4W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PWC-3.3S
ActiveAstrodyne TDI
AC/DC CONVERTER 3.3V 4W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PWC-3.3S |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | UL, cURus |
| Current - Output (Max) [Max] | 1.25 A |
| Efficiency | 65 % |
| Features | Universal Input |
| Line Regulation | 1 % |
| Load Regulation | 1 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 65 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 6-SIP Module |
| Power (Watts) | 4 W |
| Size / Dimension [x] | 1.93 in |
| Size / Dimension [x] | 49 mm |
| Size / Dimension [y] | 0.51 in |
| Size / Dimension [y] | 13 mm |
| Size / Dimension [z] | 28.5 mm |
| Size / Dimension [z] | 1.12 in |
| Standard Number | 60950-1, 60601-1 |
| Type | Open Frame |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Output 1 | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 5 | $ 11.64 | |
| 10 | $ 11.27 | |||
| 25 | $ 10.59 | |||
Description
General part information
PWC-3.3 Series
Open Frame AC DC Converters 1 Output 3.3V 1.25A 90 ~ 264 VAC Input
