62S15-M5-060C

Active

Grayhill Inc.

ROTARY ENCODER OPT 24PPR 6" CBL

Search across all available documentation for this part.

Active

Grayhill Inc.

ROTARY ENCODER OPT 24PPR 6" CBL

Technical Specifications

Parameters and characteristics for this part

Encoders 62M15-H2-060SH

Part	Rotational Life (Cycles Min)	Orientation	Encoder Type	Pulses per Revolution	Termination Style	Actuator Type	Actuator Type	Output Type
Grayhill Inc. 62S15-M5-060C	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-L9-PH	1M	Vertical	Optical	24 per Revolution	PC Pin	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-L4-060C	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-L4-040C	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-M5-040S	1M	Vertical	Optical	24 per Revolution	Cable Leads	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-H9-020C	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-L4-020C	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-M5-025CH	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-L4-PH	1M	Vertical	Optical	24 per Revolution	PC Pin	0.25	Flatted End	Quadrature (Incremental)
Grayhill Inc. 62S15-H9-040C	1M	Vertical	Optical	24 per Revolution	Cable with Connector	0.25	Flatted End	Quadrature (Incremental)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
