FAA.2S.695.CLA

Active

LEMO

CONN TRIAX PLUG STR 95OHM SOLDER

Search across all available documentation for this part.

Active

LEMO

CONN TRIAX PLUG STR 95OHM SOLDER

Technical Specifications

Parameters and characteristics for this part

Part	Housing Color	Mounting Feature	Shield Termination	Fastening Type	Center Contact Plating	Dielectric Material	Contact Termination	Body Finish	Connector Type	Ingress Protection	Operating Temperature [Min]	Operating Temperature [Max]	Mating Cycles	Body Material	Number of Ports	Shell Finish	Shell Size - Insert	Primary Material	Insert Material	Current Rating (Amps)	Contact Material	Shell Material	Color	Number of Positions	Orientation	Shielding	Contact Finish - Mating	Material Flammability Rating	Cable Group	Center Contact Material	Connector Style	Impedance	Includes
LEMO FAA.2S.695.CLA	Silver	Bulkhead - Rear Side Nut	Solder	Push-Pull	Gold	Polyetheretherketone (PEEK)	Solder Cup	Chrome	Male Pin Plug	IP50	-55 °C	250 °C	5000	Brass	1
LEMO FAA.2S.140.CTA		Bulkhead - Rear Side Nut		Push-Pull					Male Pins Plug	IP50	-55 °C	250 °C				Chrome	140	Metal	Polytetrafluoroethylene (PTFE)	40 A	Brass	Brass	Silver	1	Keyed	Shielded	Gold
LEMO FAA.2S.306.CLA		Bulkhead - Rear Side Nut		Push-Pull					Female Sockets Male Pins Plug	IP50	-55 °C	250 °C				Chrome	306	Metal	Polyetheretherketone (PEEK)	12 A	Brass Bronze	Brass	Silver	6	Keyed	Shielded	Gold	UL94 V-0
LEMO FAA.2S.650.CTA	Silver	Bulkhead - Rear Side Nut	Solder	Push-Pull	Gold	Polytetrafluoroethylene (PTFE)	Solder Cup	Chrome	Male Pin Plug	IP50	-55 °C	200 °C	1000	Brass	1														8232A 9222 Belden 8215 RG-174	Brass	Triaxial	50 Ohms	1 Connector 1 Nut

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Plug, Male Pin Panel Mount Solder Cup
