SY100S302FC
UnknownMicrochip Technology
IC GATE OR/NOR QUINT 2IN 24-CPAK
Deep-Dive with AI
Search across all available documentation for this part.
SY100S302FC
UnknownMicrochip Technology
IC GATE OR/NOR QUINT 2IN 24-CPAK
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SY100S302FC |
|---|---|
| Logic Type | NOR/OR Gate |
| Mounting Type | Surface Mount |
| Number of Circuits | 5 |
| Number of Inputs | 10 Input |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | 0 °C |
| Output Type | Differential |
| Package / Case | CerPack, 24-CQFlatPack |
| Schmitt Trigger Input | False |
| Supplier Device Package | 24-CerPack |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 75 | $ 11.64 | |
Description
General part information
100S302 Series
NOR/OR Gate Configurable 5 Circuit 10 Input (2, 2, 2, 2, 2) Input 24-CerPack
Documents
Technical documentation and resources
No documents available
