Q2-F3X-1 1/2-01-QB6IN-5

Active

Qualtek

HEATSHRINK 1.535" X 0.5' BLK 5PC

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Part Numbering Guide

Q2-F3X-1 1/2-01-QB6IN-5

Active

Qualtek

HEATSHRINK 1.535" X 0.5' BLK 5PC

Deep-Dive with AI

DocumentsDatasheet Part Numbering Guide

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q2-F3X-1 1/2-01-QB6IN-5

Color	Black
Features	Corrosion Resistant, Flame Retardant
Inner Diameter - Recovered	13 mm
Inner Diameter - Recovered	0.512 in
Length	152.4 mm
Length	6 "
Length	0.5 '
Material	Polyolefin (PO)
Operating Temperature [Max]	135 °C
Operating Temperature [Min]	-55 °C
Recovered Wall Thickness	1.24 mm
Recovered Wall Thickness	0.049 "
Shelf Life	60 Months
Shrink Temperature	70 °C
Shrinkage Ratio [Max]	3
Shrinkage Ratio [Min]	1
Storage/Refrigeration Temperature [Max]	40 °C
Storage/Refrigeration Temperature [Min]	-10 °C, -50 °F
Type	Tubing, Flexible

Q2-F3X Series

Part	Type	Color	Recovered Wall Thickness	Recovered Wall Thickness	Operating Temperature [Max]	Operating Temperature [Min]	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Features	Shrinkage Ratio [Min]	Shrinkage Ratio [Max]	Length [x]	Length [x]	Shelf Life	Shrink Temperature	Material	Values	Values	Diameter [diameter]	Length	Length	Recovered Wall Thickness	Recovered Wall Thickness	Length	Length	Inner Diameter - Recovered	Inner Diameter - Recovered	Diameter [diameter]	Values	Shelf Life Start
Qualtek Q2-F3X-3/8-01-QB48IN-25	Tubing Flexible	Black	0.76 mm	0.03 "	135 °C	-55 °C	0.118 in	2.99 mm	-50 °F -10 °C	40 °C	0.375 in	9.53 mm	Corrosion Resistant Flame Retardant	1	3	1.22 m	4 ft	60 Months	70 °C	Polyolefin (PO)
Qualtek Q2-F3X-RK1-1/2-01-6IN-14		Black												1	3						14 position	6 in	1/2
Qualtek Q2-F3X-1/2-01-MS50FT	Tubing Flexible	Black	0.81 mm		135 °C	-55 °C	0.157 in	3.99 mm	-50 °F -10 °C	40 °C	0.5 in	12.7 mm	Corrosion Resistant Flame Retardant	1	3			60 Months	70 °C	Polyolefin (PO)				15.2 m	50 ft	0.032 "
Qualtek Q2-F3X-3/16-01-SS500FT	Tubing Flexible	Black	0.024 in		135 °C	-55 °C	0.06 in	1.52 mm	-50 °F -10 °C	40 °C	0.187 in	4.75 mm	Corrosion Resistant Flame Retardant	1	3	152.4 m	500 '	60 Months	70 °C	Polyolefin (PO)							0.61 mm
Qualtek Q2-F3X-3/8-01-QB6IN-16	Tubing Flexible	Black	0.76 mm	0.03 "	135 °C	-55 °C	0.118 in	2.99 mm	-50 °F -10 °C	40 °C	0.375 in	9.53 mm	Corrosion Resistant Flame Retardant	1	3			60 Months	70 °C	Polyolefin (PO)				152.4 mm				6 "	0.5 '
Qualtek Q2-F3X-1 1/2-01-QB6IN-5	Tubing Flexible	Black	1.24 mm		135 °C	-55 °C			-50 °F -10 °C	40 °C			Corrosion Resistant Flame Retardant	1	3			60 Months	70 °C	Polyolefin (PO)				152.4 mm		0.049 "		6 "	0.5 '	13 mm	0.512 in
Qualtek Q2-F3X-RK1-1-01-6IN-8		Black												1	3						6 in	152.4 mm										1 in	8 pcs
Qualtek Q2-F3X-1/4-01-MS100FT	Tubing Flexible	Black	0.66 mm		135 °C	-55 °C	0.08 in	2.03 mm	-50 °F -10 °C	40 °C	0.25 in	6.35 mm	Corrosion Resistant Flame Retardant	1	3	30.5 m	100 ft	60 Months	70 °C	Polyolefin (PO)						0.026 "								Date of Manufacture
Qualtek Q2-F3X-3/16-01-MS100FT	Tubing Flexible	Black	0.024 in		135 °C	-55 °C	0.06 in	1.52 mm	-50 °F -10 °C	40 °C	0.187 in	4.75 mm	Corrosion Resistant Flame Retardant	1	3	30.5 m	100 ft	60 Months	70 °C	Polyolefin (PO)							0.61 mm
Qualtek Q2-F3X-1/8-01-MS100FT	Tubing Flexible	Black	0.56 mm		135 °C	-55 °C	0.039 in	0.99 mm	-50 °F -10 °C	40 °C	0.125 "	3.18 mm	Corrosion Resistant Flame Retardant	1	3	30.5 m	100 ft	60 Months	70 °C	Polyolefin (PO)						0.022 "

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 6.11
		5	$ 5.85
		10	$ 4.58
		25	$ 4.07
		50	$ 3.82
		100	$ 3.56

Description

General part information

Q2-F3X Series

Heat Shrink Tubing, Flexible 1.535" (38.99mm) 3 to 1 Black 0.500' (152.40mm, 6.00")
